SET PAGE - MENUS
Page 38 of 67
Analog I/O Settings
Analog I/O
*** Settings ***
Display
Description
Analog Out Type
4..20mA
Selects between 0..20 mA (or 0..1mA by special order) and 4..20 mA analog outputs
(all four). This parameter is common for all four Analog Outputs.
Range: 0..20 mA or 4..20mA.
Anlog Out 1 Par.
Average Current
Analog 1 output parameter. Following parameters can be selected:
• I1 (RMS current of phase 1), % of motor FLC.
• I2 (RMS current of phase 2), % of motor FLC.
• I3 (RMS current of phase 3), % of motor FLC.
• Average (RMS) of: I1, I2, I3. % of motor FLC.
• Max (RMS) of: I1, I2, I3. % of motor FLC.
• I0 (Ground fault RMS leakage current). % of motor FLC. % of Rated
Line Voltage.
• Vp1 (Phase 1 to Neutral RMS Voltage). % of motor FLC. % of Rated
Line Voltage.
• Vp2 (Phase 2 to Neutral RMS Voltage). % of motor FLC. % of Rated
Line Voltage.
• Vp3 (Phase 3 to Neutral RMS Voltage). % of motor FLC. % of Rated
Line Voltage.
• Average (RMS) of Vp1, Vp2, Vp3. % of motor FLC. % of Rated Line
Voltage.
• VL12 (Line 1 to Line 2 RMS Voltage). % of motor FLC. % of Rated
Line Voltage.
• VL23 (Line 2 to Line 3 RMS Voltage). % of motor FLC. % of Rated Line
Voltage.
• VL31 (Line 3 to Line 1 RMS Voltage). % of motor FLC. % of Rated
Line Voltage.
• Average (RMS) of VL12, VL23,VL31. % of motor FLC. % of Rated
Line Voltage.
• Power, % of rated Power.
• Power Factor (*100).
• Thermal Capacity, %.
• Max of T1, T2, T3. °C.
• Max of T4, T5, T6. °C.
• Max of T7, T8, T9. °C (or 1/10 KΩ for Thermistor).
• Max of T9, T10. °C (or 1/10 KΩ for Thermistor).
Anlog Out 1 Min.
0 % of FLC
Value for zero (0 or 4mA) output.
Range: 0..200 (Units change with parameter).
Anlog Out 1 Max.
200 % of FLC
Value for maximum (20mA, or 1mA by special order) output.
Range: 0..250 (Units change with parameter).
Anlog Out 2 Par.
AVG. LINE Volts
Analog 2 output parameter.
Range: Same as for Anlog Out 1 par.
Anlog Out 2 Min.
Value for zero (0 or 4mA) output.
