DATA PAGE - MENUS
Page 59 of 67
Statistical Data
Total Run Time
10137.5 hours
Total run time since commissioning.
Range: 0-30,000 hours.
Total # of Start
1017
Total number of starts since commissioning.
Range: 0-65535
Total # of Trips
12
Total number of trips since commissioning.
Range: 0-65535
Last Strt Period
5.2 Sec.
Last start time duration.
Range: 0-255 seconds.
Last Start Max I
350 amp.
Peak current (highest of three phases) during last start.
Range: 0-24000 amp.
Total Energy
457,235 KWH
Total (since last clearing of statistical data) accumulated motor active energy.
Range: 0-10,000,000 KWH.
Total React. En.
265,107 KVARH
Total (since last clearing of statistical data) accumulated motor reactive energy.
Range: 0-10,000,000 KVARH.
Minimum Voltage
395 volt
Latched (since last reset) minimum value of RMS Line voltage (average of
three phase). Measured while motor is starting or running.
Reset is possible when message is displayed, by pressing Reset Key.
Maximum Voltage
395 volt
Latched (since last reset) maximum value of RMS Line voltage (average of
three phases). Measured while motor is starting or running.
Reset is possible when message is displayed, by pressing Reset Key.
Minimum Current
73 Amp.
Latched (since last reset) minimum value of RMS Line Currents (average of
three phases), Measure starts 20 seconds after motor is running.
Reset is possible when message is displayed, by pressing Reset Key.
Maximum Current
73 Amp.
Latched (since last reset) maximum value of RMS Line Currents (average of
three phases), Measure starts 20 seconds after motor is running.
Reset is possible when message is displayed, by pressing Reset Key.
Min. Frequency
49.9 Hz
Latched (since last rest) minimum value of mains frequency.
Reset is possible when message is displayed, by pressing Reset Key.
Max. Frequency
49.9 Hz
Latched (since last rest) maximum value of mains frequency.
Reset is possible when message is displayed, by pressing Reset Key.
Statistical Data
- **** -
To Next Page
