Solcon MPS 3000 User Manual

DATA PAGE - MENUS
Page 60 of 67
Fault Data
Fault Data
- **** -
Last Trip
RTD 3 Level 2
Last active fault that was Enabled as a Trip.
Range: all 52 faults.
Last Alarm
Load Increased
Last active fault that was Enabled as an Alarm.
Range: all 52 faults.
Trip I1, I2, I3
129 132 130 A
Values of three line (motor) currents before last trip.
Range: 0-24000 amp.
Trip GND Current
0 amp.
Values of Ground Fault current before last trip.
Range: 0-24000 amp.
Trip Vp1, Vp2,Vp3
277 277 277 V
Values of phase to neutral voltages before last trip.
Range: 0-25000 volt.
Last 10 Trips:
Header of next 10 screens showing the details of last 10 trips with
time stamps.
External Fault 1
08:32 08/05/ 02
Last Trip with its time stamp.
RTD 1 LEVEL 2
13:33 06/13/02
Values of phase to neutral voltages before last trip.
Range: 0-25000 volt.
O/C LEVEL 2 -
Short
11:26 03/21/02
Values of phase to neutral voltages before last trip.
Range: 0-25000 volt.
Next 7 Faults (10 in total) are listed here.
