Solcon MPS 3000 User Manual

MENU
Page 24 of 67
MAX TIME IN STAR
PARAM. SETTINGS
LOCKED OUT
UNBALANCE MIN T
5 SEC.
TRANSITION TIME U/B LEVEL 2 MAX T
30 SEC.
Set Page
Set Page
Set Page Set Page
PAGE 4 PAGE 5 PAGE 6
PAGE 7
PAGE 8
POWER
*** SETTINGS ***
TEMPERATURE
*** SETTINGS ***
ANALOG I/O
*** SETTINGS ***
TRIPPING / ALARM
*** OPTIONS ***
COMMUNICATION
*** SETTINGS ***
SELECT SELECT SELECT
SELECT
SELECT
PRESS KEYS TO CHANGE PARAMETER VALUE
RATED PF AT FLC
0.88 LAG
RTD TYPE
PLATINUM 100 OHM
ANALOG OUT TYPE
4..20mA
MAX START TIME
TRIP: DISABLE
BAUD RATE
19200
UNDER PWR LEVEL 1
45%
SENSOR 7-10 TYPE
RTD
ANLOG OUT 1 PAR.
AVERAGE CURRENT
MAX START TIME
ALARM: ENABLE
ADDRESS NUMBER
248
U/P LEVEL 1 DELAY
30 SEC.
T1 LEVEL 1
120 EC
ANLOG OUT 1 MIN.
0 % OF FLC
MAX START TIME
AUTO RST: DSABL
S.LINK SAVE LOCK
LOCKED
UNDER PWR LEVEL 2
25%
T1 LEVEL 2
140 EC
ANLOG OUT 1 MAX.
200% OF FLC
MAX START TIME
PANEL RST: ENABL
20 MODBUS # for
user selcted group of
data.
U/P LEVEL 2 DELAY
30 SEC.
Same settings for
RTD 2..6
ANLOG OUT 2 PAR.
AVG. LINE VOLTS
MAX START TIME
REMOT RST: ENABL
LOW POWER FACTOR
0.8 LAG
T7 LEVEL 1
80 EC
ANLOG OUT 2 MIN.
0 % OF Vn
MAX START TIME
OUTPUT A: DISABL
LOW PF DELAY
30 SEC.
T7 LEVEL 2
100 EC
ANLOG OUT 2 MAX.
200% OF Vn
MAX START TIME
OUTPUT B: DISABL
KWH PER PULSE
OFF
Same settings for
RTD 8 & 9
ANLOG OUT 3 PAR.
THERMAL CAPACITY
Similar settings for next
50 Fault protections
T10 LEVEL 1
80 EC
ANLOG OUT 3 MIN.
0 % OF CAPACITY
ANALOG INPUT # 4
TRIP: DISABLE
T10 LEVEL 2
100 EC
ANLOG OUT 3 MAX.
200% OF CAPACITY
ANALOG INPUT # 4
ALARM: DISABLE
ANLOG OUT 4 PAR.
MAX OF T1..T3
ANALOG INPUT # 4
AUTO RST: DSABL
Note: If Sensor 7-10
are thermistors, then
units of 7-10 are KΩ
ANLOG OUT 4 MIN.
0 °C
ANALOG INPUT # 4
PANEL RST: ENABL
ANLOG OUT 4 MAX.
200 °C
ANALOG INPUT # 4
REMOT RST: ENABL
ANALOG IN 1 TYPE
4..20 mA
ANALOG INPUT # 4
OUTPUT A: DISABL
ANLOG IN 1 LEVEL
ABOVE 50 %
ANALOG INPUT # 4
OUTPUT B: DISABL
ANLOG IN 1 DELAY
10 SEC.
