SSL UF1 User Guide
SSL Chanel Strip Soft Key & V-Pot Assignments
The tables below describe the mapping of 360°-enabled channel strips across the UF1 soft keys and V-Pots surrounding the large
LCD.
Channel Strip 2
Page Soft Key 1 Soft Key 2 Soft Key 3 Soft Key 4 V-Pot 1 V-Pot 2 V-Pot 3 V-Pot 4
1 Ø SOLO SAFE S/C LISTEN Width Out Trim Comp Mix
2 In Trim High Pass Low Pass
3 LF BELL E EQ LF Gain LF Freq
4 E EQ LMF Gain LMF Freq Q
5 E EQ HMF Gain HMF Freq Q
6 HF BELL E EQ HF Gain HF Freq
7 FAST ATTACK PEAK S/C LISTEN DYNAMICS Ratio Threshold Release
8 EXPAND FAST ATTACK DYNAMICS Range Threshold Release Hold
4K B
Page Soft Key 1 Soft Key 2 Soft Key 3 Soft Key 4 V-Pot 1 V-Pot 2 V-Pot 3 V-Pot 4
1 Ø PRE SOLO SAFE S/C LISTEN Width Mic Out Trim Comp Mix
2 In Trim High Pass Low Pass
3 LF BELL EQ LF Gain LF Freq
4 EQ LMF Gain LMF Freq Q
5 EQ HMF Gain HMF Freq Q
6 HF BELL EQ HF Gain HF Freq
7 S/C LISTEN DYNAMICS Ratio Threshold Release
8 EXPAND DYNAMICS Range Threshold Release
