Live Tutorial
78
SSL UF1 User Guide
V-Pot Assignment Modes
UF1 offers direct access to Live's main Mackie Control V-Pot assignment modes. These V-Pot assignment modes are accessed
via the keys labelled below: 1. PAN, 2. SEND, 3. DEVICE (PLUG-IN), 4. I/O.
1 - PAN
Assigns the Pan controls to the V-Pots on UF1. Pushing a V-Pot will default it to the centre position.
2 - SEND
Assigns the Send controls for the currently selected track to the V-Pots on UF1. The 2 blue digits in the centre of the LCD inform
you the number of the selected track. Pushing a V-Pot will default the Send to off. Use the 5-8 key to access sends E to H on the
selected track.
3 - DEVICE (Plug-ins)
Live's own instruments and also third party audio plug-ins can be controlled directly from UF1. Once you have pressed the DEVICE
key to enter this mode, do the following:
• Select the track on which you want to control the plug-in.
• The name(s) of the plug-ins will appear in the LowLCD section of UF1.
• Push the V-Pot of the plug-in you wish to control.
• The parameters of the plug-in will be assigned across the V-Pots. Use a combination
of the 5-8 key and PAGE LEFT and PAGE RIGHT keys in the Secondary Transport
section to access all the parameters the device has.
• Once you have finished, press the DEVICE key again to return to viewing the names
of the plug-ins you have on the currently selected track.
4 - I/O
Allows you to set the I/O settings for each track on the V-Pots. Pressing the I/O key repeatedly will cycle through the following
options: Input Type, Input Source, Output Type and Output Destination.
2 43
The Pan Key is located on
the Soft Key above the Small
LCD
Send & Device (Plug-in) is available
on Soft Key Page 1
I/O is available on Soft Key Page 2.
Use the 5-8 key, in combination with
the PAGE LEFT and PAGE RIGHT
keys to access all the parameters.
1
