SOLIS S6 Series User Manual

User Manual
3.3.1 Wall mounting
3. Installation
13
1. Use the suitable mounting screws to attach the bracket on the wall.
Figure 3.8
2. Take off the Protective cover on the back of AC wiring box.
Figure 3.7 Inverter wall mounting
Bracket
Suitable mounting screws
Torque:22.1-25.8 ft.lbs
3. Take off the Protective cover in the side of inverter.
Figure 3.9

SOLIS S6 Series Specifications

General

Number of MPPTs	2
THDi	<3%
DC Switch	Yes
Max. AC Output Power	6000W
Rated AC Output Power	6000W
Max. AC Apparent Power	6000VA
Rated Grid Voltage	230V
Grid Voltage Range	180V-280V
Rated Grid Frequency	50Hz/60Hz
Grid Frequency Range	45-55Hz / 55-65Hz
Protection	DC Reverse-Polarity Protection, AC Short-Circuit Protection
Operating Temperature Range	-25°C to 60°C
Cooling	Natural Cooling
Communication	WiFi/GPRS
