SOLIS S6 Series User Manual

User Manual
6.7.13 Debug Parameter
Figure 6.44
Debug Parameter as shown as below:
This section is applicable to maintenance personnel only.
Press the UP/DOWN keys to scroll through items. Press the ENTER key to select.
Press the DOWN key to scroll and press the UP key to change the value.
Press the ENTER key to save the setting. Press the ESC key to cancel.
changes and return to the previous menu.
→
S16DAT1: +0000
S16DAT2: +0000
S16DAT3: +0000
S16DAT4: +0000
S16DAT5: +0000
S16DAT6: +0000
S16DAT7: +0000
S16DAT8: +0000
6.7.14 FAN Test
Figure 6.45
Selecting “Fan Test” displays the sub-menu shown below:
This section is applicable to maintenance personnel only.
Are you sure?
YES=<ENT> NO=<ESC>
Fan Test is a factory test function. Press the ENTER key to start the test.
Press the ESC key to return to the previous menu. (Refer to section 7.2 for fan maintenance
and replacement).
6. Normal operation
58
NOTE
NOTE

SOLIS S6 Series Specifications

General

Number of MPPTs	2
THDi	<3%
DC Switch	Yes
Max. AC Output Power	6000W
Rated AC Output Power	6000W
Max. AC Apparent Power	6000VA
Rated Grid Voltage	230V
Grid Voltage Range	180V-280V
Rated Grid Frequency	50Hz/60Hz
Grid Frequency Range	45-55Hz / 55-65Hz
Protection	DC Reverse-Polarity Protection, AC Short-Circuit Protection
Operating Temperature Range	-25°C to 60°C
Cooling	Natural Cooling
Communication	WiFi/GPRS
