SOLIS S6 Series User Manual

User Manual
6.6.3 Version
The screen shows the model version of the inverter. And the screen will show the
software ver by pressing the UP and DOWN at the same time.(see Figure 6.7).
6.6.4 Daily Energy
The function is for checking the energy generation for selected day.
Figure 6.8 Select date for daily energy
YES=<ENT> NO=<ESC>
Select: 2019-01-01
Press DOWN key to move the cursor to day, month and year, press UP key to change the digit.
Press Enter after the date is fixed.
2019-01-01: 051.3kWh
2019-01-01: 061.5kWh
Figure 6.9 Daily energy
Press UP/D OWN key to move one date from another.
Model: 08
Software Version: D20001
Figure 6.7 Model Version and Software Version
6.6.5 Monthly Energy
YES=<ENT> NO=<ESC>
Select: 2019-01
Figure 6.10 Select month for monthly energy
The function is for checking the energy generation for selected month.
2019-01: 0510kWh
2019-01: 0610kWh
Figure 6.11 Monthly energy
Press UP/D OWN key to move one date from another.
Press DOWN key to move the cursor to day and month, press UP key to change the digit.
Press Enter after the date is fixed.
6. Normal operation
40

SOLIS S6 Series Specifications

General

Number of MPPTs	2
THDi	<3%
DC Switch	Yes
Max. AC Output Power	6000W
Rated AC Output Power	6000W
Max. AC Apparent Power	6000VA
Rated Grid Voltage	230V
Grid Voltage Range	180V-280V
Rated Grid Frequency	50Hz/60Hz
Grid Frequency Range	45-55Hz / 55-65Hz
Protection	DC Reverse-Polarity Protection, AC Short-Circuit Protection
Operating Temperature Range	-25°C to 60°C
Cooling	Natural Cooling
Communication	WiFi/GPRS
