SOLIS S6 Series User Manual

User Manual
6.7 Advanced Settings - Technicians Only
NOTE
To access to this area is for fully qualified and accredited technicians only.
Please follow 6.4 to enter password to access this menu.
Select Advanced Settings from the Main Menu to access the following options:
1. Select Standard
2. Grid ON/OFF
3. Clear Energy
4. Reset Password
5. Power Control
6. Calibrate Energy
7. Special Settings
8. STD. Mode Settings
9. Restore Settings
10. HMI Update
11. External EPM set
12. Restart HMI
13. Debug Parameter
14.DSP Update
15.Compensation Set
16.I/V Curve
This function is used to select the grid reference standard (see Figure 6.16).
YES=<ENT> NO=<ESC>
Standard:UL-480V-A
Figure 6.16
6.7.1 Selecting Standard
Selecting the “User-Def” menu will access the following sub-menu (see Figure 6.17).
Figure 6.17
OV-G-V1: 260V
OV-G-V1-T: 1.0S
Below is the range for each setting for use in the User-Def function. You may change the limit
manually thus creating a custom grid profile by using this function.
→
6. Normal operation
42

SOLIS S6 Series Specifications

General

Number of MPPTs	2
THDi	<3%
DC Switch	Yes
Max. AC Output Power	6000W
Rated AC Output Power	6000W
Max. AC Apparent Power	6000VA
Rated Grid Voltage	230V
Grid Voltage Range	180V-280V
Rated Grid Frequency	50Hz/60Hz
Grid Frequency Range	45-55Hz / 55-65Hz
Protection	DC Reverse-Polarity Protection, AC Short-Circuit Protection
Operating Temperature Range	-25°C to 60°C
Cooling	Natural Cooling
Communication	WiFi/GPRS
