SOLIS S6 Series User Manual

1. Introduction
1.1 Product Description
1
User Manual
Figure 1.1 Front view
LED lights
LCD display
4 buttons
AC Switch
Solis Three phase Inverters convert DC power from the photovoltaic(PV) array
into alternating current(AC) power that can satisfy local loads as well as feed the power
distribution grid.
This manual covers the three phase inverter models listed below:
S6-GC25K-US, S6-GC33K-US, S6-GC36K-US, S6-GC40K-US,
S6-GC50K-US, S6-GC60K-US. S6-GC30K-LV-US
Figure 1.2 Bottom view
DC Switch
DC input
Vent
COM
AC output
COM

SOLIS S6 Series Specifications

General

Number of MPPTs	2
THDi	<3%
DC Switch	Yes
Max. AC Output Power	6000W
Rated AC Output Power	6000W
Max. AC Apparent Power	6000VA
Rated Grid Voltage	230V
Grid Voltage Range	180V-280V
Rated Grid Frequency	50Hz/60Hz
Grid Frequency Range	45-55Hz / 55-65Hz
Protection	DC Reverse-Polarity Protection, AC Short-Circuit Protection
Operating Temperature Range	-25°C to 60°C
Cooling	Natural Cooling
Communication	WiFi/GPRS
