User Manual
Figure 3.17 Combination bolt
c. Align the mounting plate with the holes, Insert the combination bolt (M10X40)through the
mounting plate into the hole. Secure the bracket to the metal frame firmly with the supplied
fastener. Torque the nut to 25.8 ft.lbs.
3. Installation
18
d. Install the inverter as described in figures 3.8-3.12
