46
14.10
DIP switches
ON
1
2
3
4
FUNCTION
ON
OFF
1
Automatic
closing
function
Activated
Deactivated
2
Pre-warning
time
W
arning
light blinks
4 seconds
before and
during door
movement
Blinks during
door movement
3
Partial
opening/
lighting
function
Partial opening
activated/
lighting
function
deactivated
Partial opening
deactivated/
lighting function
activated
4
Safety edge
Safety contact
strip activated
= STOP
, door
reverses
Safety contact
strip activated
= STOP
,
door opens
completely
14.1
1
Resetting the control unit
15 s
1 s
5 s
10 s
Reset of the
safety inputs
Reset of the
programmed
run times
See
“14.1
1 Resetting the control unit” on page 46.
14.
Brief instructions
45
47
Table of Contents
1. About this Installation and Operating Manual
4
1.1 Storage and circulation of the Installation and Operating Manual
4
1.2 Important for translations
4
1.3 Description of the product type
4
1.4 Target groups of the Installation and Operating Manual
4
1.5 Explanation of warning symbols and notes
4
1.6 Special warning symbols and mandatory signs
5
1.7 Information regarding the depiction of text
5
1.8 Intended use
6
1.9 Improper use
6
1.10 Qualifications of personnel
6
1.11 Information for the user
7
2. General safety instructions
8
2.1 Basic safety instructions for operation
8
2.2 Additional safety information for the radio remote control
9
2.3 Information on operation and remote control
9
2.4 Simplified Declaration of Conformity
9
3. Description of function and product
10
3.1 Safety equipment
10
3.2 Product designation
10
3.3 Scope of delivery
11
3.4 Dimensions
11
3.5 Technical data
12
3.6 Overview of connection options
13
3.7 Door types
13
4. Tools and protective equipment
14
4.1 Required tools
14
4.2 Personal protective equipment
14
5. Declaration of Conformity
15
6. Installation
16
6.1 Important information on installation
16
6.2 Installing the control unit
16
7. Electrical connection
18
7.1 Important information on electrical connection
18
7.2 Connection options
19
7.3 Slots for accessories/fuses
20
7.4 Additional information on connections and accessories
21
7.5 SOMlink
21
7.6 Mains connection
21
7.7 Information on connecting accessories
21
8. Initial operation
22
8.1 DIP switch initial position
22
8.2 Checking the direction of running
22
8.3 Setting the motor limit switches
23
8.4 Closing the housing cover
23
8.5 Setting the run time (run time monitoring)
23
8.6 DIP switches
24
8.7 Explanation of the radio channels
26
8.8 Selection of the radio channels
26
8.9 Programming the transmitter
26
8.10 Information on Memo
27
8.11 Cancelling programming mode
27
8.12 Deleting a transmitter button from the radio channel
27
8.13 Deleting transmitter completely from the receiver
27
8.14 Deleting a radio channel in the receiver
27
8.15 Deleting all radio channels in the receiver
28
8.16 Programming a second transmitter by radio (HFL)
28
8.17 Resetting the control unit
28
9. Final test/handover
30
9.1 Testing obstacle detection
30
9.2 Handover of the door system
30
10. Operation
31
10.1 Safety information on operation
31
10.2 Operation using the button pad in the housing cover
31
10.3 Operation with external button (2-way/3-way)
32
10.4 Operation using handheld transmitter
32
10.5 Obstacle detection
33
10.6 Operation after a power failure
33
10.7 Dead man mode/hold to run mode
33
11. Maintenance and care
34
11.1 Safety instructions for maintenance and care
34
11.2 Reading out the number of cycles via LEDs
35
11.3 Reading out the number of cycles via SOMlink
35
11.4 Changing light bulbs
35
12. Troubleshooting
36
12.1 Safety instructions for troubleshooting
36
12.2 Troubleshooting
36
12.3 Time sequences of operator lighting in normal mode and in case of faults
37
13. Taking out of operation, storage and disposal
42
13.1 Taking the control unit out of operation and disassembly
42
13.2 Storage
42
13.3 Disposal of waste
42
14. Brief instructions
43
15. Connection overview and DIP switches
47
