SonicWall SonicWave Deployment Guide
Hardware Overview
10
Solid Green Link established at 100 Mbps or 10 Mbps
Blinking Green Active traffic at 100 Mbps or 10 Mbps
5 GHz Radio LED
LED Color Description
Off 5 GHz radio is off
Solid Green 5 GHz radio is on
Blinking Green Active traffic on 5 GHz radio
2.4 GHz Radio LED
LED Color Description
Off 2.4 GHz radio is off
Solid Green 2.4 GHz radio is on
Blinking Green Active traffic on 2.4 GHz radio
LED Pattern During Firmware or SafeMode Bootup
LEDs LED Color Description
LAN Green - Heartbeat The three LEDs blink simultaneously in a
heartbeat pattern while booting is in
progress:
On - On - Off
5 GHz Radio Green - Heartbeat
2.4 GHz Radio Green - Heartbeat
LED Pattern for Reset Button Hold Durations
LEDs LED Color Description
LAN Blinking Green The three LEDs blink simultaneously at a slow
or medium rate:
• Slow blink – Press Reset button 3 sec
• Med blink – Press Reset button 8 sec
5 GHz Radio Blinking Green
2.4 GHz Radio Blinking Green
LED Pattern in SafeMode
LEDs LED Color Description
LAN Green - Flow The three LEDs turn on serially (one by one)
and then turn off serially in a flow pattern
while the <Short Product Name> is in
SafeMode.
5 GHz Radio Green - Flow
2.4 GHz Radio Green - Flow
NOTE: The LEDs are disabled by default. You can enable them in the SonicWave
provisioning profile or individual SonicWave entry in SonicOS on the firewall.
LAN LED
LED Color Description
