SonicWall SonicWave Deployment Guide
Hardware Overview
14
PoE OUT LED
LED Color Description
Off PoE power output is disabled
Solid Green PoE power output is enabled
LED Pattern During Firmware or SafeMode Bootup
LEDs LED Color Description
LAN Green - Heartbeat The three LEDs blink simultaneously in a
heartbeat pattern while booting is in
progress:
On - On - Off
5 GHz Radio Green - Heartbeat
2.4 GHz Radio Green - Heartbeat
LED Pattern for Reset Button Hold Durations
LEDs LED Color Description
LAN Blinking Green The three LEDs blink simultaneously at a slow
or medium rate:
• Slow blink – Press Reset button 3 sec
• Med blink – Press Reset button 8 sec
5 GHz Radio Blinking Green
2.4 GHz Radio Blinking Green
LED Pattern in SafeMode
LEDs LED Color Description
LAN Green - Flow The three LEDs turn on serially (one by one)
and then turn off serially in a flow pattern
while the SonicWave 224w is in SafeMode.
5 GHz Radio Green - Flow
2.4 GHz Radio Green - Flow
NOTE: The LEDs are disabled by default. You can enable them in the SonicWave
provisioning profile or individual SonicWave entry in SonicOS on the firewall.
