Sonoscape E1 User Manual

10 Probes and Biopsy Brackets
134 Basic User Manual
3. Hold the probe and unroll the sheath onto the probe. Pull the probe sheath tightly over
the face of the probe to remove wrinkles.
4. Slide the inner part into the top housing and push forward until it clicks.
5. Align the biopsy bracket with the orientation mark of probe.
Orientation Mark
6. Attach the biopsy bracket to the probe and fasten the biopsy bracket with the locking
screw.
7. Insert the biopsy needle into the tube and ensure the biopsy bracket is firmly attached
to the probe .

Sonoscape E1 Specifications

General

Type	Portable Ultrasound System
Display	15-inch LCD
Transducer Ports	2
Cine Loop	Yes
Imaging Modes	Color Doppler, Power Doppler
Applications	Obstetrics, Gynecology, Vascular, Musculoskeletal
Probe Connectors	2
Ports	VGA, USB, Ethernet
Supported Probes	Convex, Linear, Phased Array
