Sonoscape E1 User Manual

2 System Overview
18 Basic User Manual
No. Name Description
23 Freeze Freeze the image in the real time mode or restore the real time
scan.
24 M Enter or exit the M mode.
PW Enter or exit the PW mode.
CFM Reserved
B Enter the B mode.
25 Auto/Gain
●
Press it to automatically optimize an image.
●
Rotate it to adjust the gain of the current mode.
26 Standby
Indicator
Indicates the system standby status.
27 Charging
Indicator
Indicates the battery charging status. For details, refer to Section
3.2.4 Status Indicator.
28 Discharging
indicator
Indicates the battery discharging status. For details, refer to
Section 3.2.4 Status Indicator.
29 Image Save an image in the real time mode or frozen mode.
30 Cine
●
The function of this key can be set through the system.
●
The cine storage is the default function. For details, refer to
Section 4.1.3 Save Settings.
31 Print Print the current screen displayed on the monitor.
32 Depth Adjust the scan depth.
33 Zoom
●
Press it to activate or exit the zoom feature.
●
Rotate it to magnify the interest area of the ultrasound
image.
34 Focus Adjust the focus position.
35 TGC Adjust the TGC settings at different scan depth.
36 NEXT Key
●
This key corresponds to the function key located at the
bottom of the screen.
●
Press it to go to the next or previous page.

Sonoscape E1 Specifications

General

Type	Portable Ultrasound System
Display	15-inch LCD
Transducer Ports	2
Cine Loop	Yes
Imaging Modes	Color Doppler, Power Doppler
Applications	Obstetrics, Gynecology, Vascular, Musculoskeletal
Probe Connectors	2
Ports	VGA, USB, Ethernet
Supported Probes	Convex, Linear, Phased Array
