64
CDP-M400CS
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
1-683-730-13 LED BOARD
**********
< CAPACITOR >
C801 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CNP504 1-785-328-11 PIN, CONNECTOR (LIGHT ANGRE) 2P
< DIODE >
D801 8-719-069-45 DIODE SELU5E23C-TP15
< RESISTOR >
R801 1-249-401-11 CARBON 47 5% 1/4W
*************************************************************
1-683-726-13 LOADING SW BOARD
*****************
< RESISTOR >
R622 1-247-831-91 CARBON 1K 5% 1/4W
R623 1-249-421-11 CARBON 2.2K 5% 1/4W
< SWITCH >
S621 1-786-154-11 SWITCH, ROTARY (LOADING)
*************************************************************
1-683-725-13 LOCK SW BOARD
**************
< SWITCH >
S622 1-771-604-11 SWITCH, DETECTION (LOCK)
*************************************************************
A-1082-286-A MAIN BOARD, COMPLETE
*********************
* 3-309-144-21 HEAT SINK
* 4-363-146-21 HEAT SINK, V.OUT
7-685-871-01 SCREW +BVTT 3X6 (S)
< CAPACITOR >
C301 1-126-965-91 ELECT 22uF 20% 50V
C302 1-130-471-00 MYLAR 0.001uF 5% 50V
C303 1-137-367-11 MYLAR 0.0033uF 5% 50V
C304 1-126-965-91 ELECT 22uF 20% 50V
C305 1-126-965-91 ELECT 22uF 20% 50V
C307 1-126-960-11 ELECT 1uF 20% 50V
C310 1-164-159-11 CERAMIC 0.1uF 50V
C311 1-164-159-11 CERAMIC 0.1uF 50V
C321 1-126-963-11 ELECT 4.7uF 20% 50V
C327 1-124-282-00 ELECT 22uF 20% 25V
C328 1-162-290-31 CERAMIC 470PF 10% 50V
C329 1-126-963-11 ELECT 4.7uF 20% 50V
C401 1-126-965-91 ELECT 22uF 20% 50V
C402 1-130-471-00 MYLAR 0.001uF 5% 50V
C403 1-137-367-11 MYLAR 0.0033uF 5% 50V
C404 1-126-965-91 ELECT 22uF 20% 50V
C405 1-126-965-91 ELECT 22uF 20% 50V
C407 1-126-960-11 ELECT 1uF 20% 50V
C410 1-164-159-11 CERAMIC 0.1uF 50V
C411 1-164-159-11 CERAMIC 0.1uF 50V
C427 1-124-282-00 ELECT 22uF 20% 25V
C428 1-162-290-31 CERAMIC 470PF 10% 50V
C501 1-164-159-11 CERAMIC 0.1uF 50V
C502 1-104-658-91 ELECT 100uF 20% 10V
C503 1-164-159-11 CERAMIC 0.1uF 50V
C504 1-164-159-11 CERAMIC 0.1uF 50V
C505 1-164-159-11 CERAMIC 0.1uF 50V
C508 1-161-494-00 CERAMIC 0.022uF 25V
C509 1-161-494-00 CERAMIC 0.022uF 25V
C510 1-161-494-00 CERAMIC 0.022uF 25V
C511 1-161-494-00 CERAMIC 0.022uF 25V
C512 1-161-494-00 CERAMIC 0.022uF 25V
C513 1-164-159-11 CERAMIC 0.1uF 50V
C514 1-164-159-11 CERAMIC 0.1uF 50V
C515 1-161-494-00 CERAMIC 0.022uF 25V
C516 1-164-159-11 CERAMIC 0.1uF 50V
C517 1-161-494-00 CERAMIC 0.022uF 25V
C518 1-164-159-11 CERAMIC 0.1uF 50V
C519 1-126-960-11 ELECT 1uF 20% 50V
C541 1-131-679-31 FILM 0.01uF 5% 50V
C542 1-136-287-11 FILM 0.0047uF 5% 100V
C543 1-131-700-31 FILM 0.47uF 5% 50V
C550 1-110-489-11 CAPACITOR 1F 5.5V
C551 1-164-159-11 CERAMIC 0.1uF 50V
C591 1-104-658-91 ELECT 100uF 20% 10V
C592 1-104-658-91 ELECT 100uF 20% 10V
C593 1-104-658-91 ELECT 100uF 20% 10V
C594 1-104-658-91 ELECT 100uF 20% 10V
C913 1-126-767-11 ELECT 1000uF 20% 16V
C914 1-126-767-11 ELECT 1000uF 20% 16V
C917 1-126-925-91 ELECT 470uF 20% 10V
C923 1-126-767-11 ELECT 1000uF 20% 16V
C927 1-126-925-91 ELECT 470uF 20% 10V
C928 1-126-925-91 ELECT 470uF 20% 10V
C933 1-126-933-11 ELECT 100uF 20% 16V
C934 1-126-933-11 ELECT 100uF 20% 16V
C935 1-104-658-91 ELECT 100uF 20% 10V
C936 1-126-962-11 ELECT 3.3uF 20% 50V
C938 1-126-925-91 ELECT 470uF 20% 10V
C939 1-164-159-11 CERAMIC 0.1uF 50V
C941 1-126-935-11 ELECT 470uF 20% 16V
C942 1-126-935-11 ELECT 470uF 20% 16V
C943 1-126-948-11 ELECT 100uF 20% 35V
C944 1-126-948-11 ELECT 100uF 20% 35V
C945 1-104-658-91 ELECT 100uF 20% 10V
C950 1-164-159-11 CERAMIC 0.1uF 50V
C951 1-164-159-11 CERAMIC 0.1uF 50V
C952 1-164-159-11 CERAMIC 0.1uF 50V
C953 1-104-658-91 ELECT 100uF 20% 10V
C954 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN501 1-779-299-11 CONNECTOR, FFC (LIF (NON-ZIF)) 31P
LED LOADING SW LOCK SW MAIN
