65
CDP-M400CS
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
CN502 1-784-739-11 CONNECTOR, FFC 17P
CN503 1-785-332-11 PIN, CONNECTOR (LIGHT ANGLE) 6P
CN505 1-785-335-11 PIN, CONNECTOR (LIGHT ANGLE) 9P
CN506 1-785-331-11 PIN, CONNECTOR (LIGHT ANGLE) 5P
CN801 1-785-333-11 PIN, CONNECTOR (LIGHT ANGLE) 7P
* CN901 1-564-524-11 PLUG, CONNECTOR 9P
CN903 1-785-335-11 PIN, CONNECTOR (LIGHT ANGLE) 9P
CN1101 1-784-921-11 PIN, CONNECTOR 4P
< DIODE >
D327 8-719-991-33 DIODE 1SS133T-77
D329 8-719-991-33 DIODE 1SS133T-77
D501 8-719-991-33 DIODE 1SS133T-77
D502 8-719-991-33 DIODE 1SS133T-77
D503 8-719-991-33 DIODE 1SS133T-77
D551 8-719-991-33 DIODE 1SS133T-77
D941 8-719-109-93 DIODE RD6.2ESB2
D942 8-719-110-53 DIODE RD20ESB2
< IC >
IC302 8-749-015-59 IC BA4558-HT
IC401 8-749-015-59 IC BA4558-HT
IC402 8-749-015-59 IC BA4558-HT
IC501 6-803-443-01 IC uPD703030BYGF-M13-3BA
IC504 8-759-825-10 IC BS62LV256SC-70 (T)
IC901 8-749-017-31 IC GP1FA550TZ (DIGITAL OPTICAL OUT)
IC910 8-759-231-53 IC TA7805S
IC920 8-759-071-48 IC TA7807S
IC921 8-759-231-53 IC TA7805S
IC930 8-759-173-39 IC NJU7201L50-T3
IC931 8-759-658-02 IC BA3993F
< JACK >
* J901 1-764-188-11 JACK (SMALL TYPE) (DIA. 3.5)
(CONTROL A1 II)
* J902 1-764-188-11 JACK (SMALL TYPE) (DIA. 3.5)
(CONTROL A1 II)
J903 1-794-012-11 JACK, PIN 4P (2ND CD IN,ANALOG OUT)
< COIL >
L501 1-410-396-41 FERRITE 0.45uH
L921 1-410-396-41 FERRITE 0.45uH
L950 1-410-503-11 INDUCTOR 3.3uH
< TRANSISTOR >
Q321 8-729-900-89 TRANSISTOR DTC144ES
Q322 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q323 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q324 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q325 8-729-900-65 TRANSISTOR DTA144ES
Q326 8-729-029-46 TRANSISTOR DTA143ESA
Q327 8-729-900-65 TRANSISTOR DTA144ES
Q328 8-729-900-65 TRANSISTOR DTA144ES
Q329 8-729-900-65 TRANSISTOR DTA144ES
Q421 8-729-900-89 TRANSISTOR DTC144ES
Q422 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q423 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q424 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q425 8-729-900-65 TRANSISTOR DTA144ES
Q426 8-729-029-46 TRANSISTOR DTA143ESA
Q501 8-729-900-89 TRANSISTOR DTC144ES
Q502 8-729-029-46 TRANSISTOR DTA143ESA
Q551 8-729-030-08 TRANSISTOR DTC144VSA
Q552 8-729-900-65 TRANSISTOR DTA144ES
Q562 8-729-900-65 TRANSISTOR DTA144ES
Q570 8-729-116-02 TRANSISTOR BA1A4M-TP
Q571 8-729-116-02 TRANSISTOR BA1A4M-TP
Q572 8-729-116-02 TRANSISTOR BA1A4M-TP
Q576 8-729-422-57 TRANSISTOR UN4111
Q941 8-729-140-97 TRANSISTOR 2SB734-34
Q950 8-729-620-05 TRANSISTOR 2SC2603-EF
< RESISTOR >
R301 1-247-895-00 CARBON 470K 5% 1/4W
R302 1-247-843-11 CARBON 3.3K 5% 1/4W
R303 1-247-843-11 CARBON 3.3K 5% 1/4W
R306 1-247-895-00 CARBON 470K 5% 1/4W
R307 1-249-422-11 CARBON 2.7K 5% 1/4W
R309 1-247-847-91 CARBON 4.7K 5% 1/4W
R310 1-249-429-11 CARBON 10K 5% 1/4W
R311 1-249-429-11 CARBON 10K 5% 1/4W
R312 1-249-429-11 CARBON 10K 5% 1/4W
R313 1-247-895-00 CARBON 470K 5% 1/4W
R314 1-249-409-11 CARBON 220 5% 1/4W
R315 1-249-409-11 CARBON 220 5% 1/4W
R317 1-247-847-91 CARBON 4.7K 5% 1/4W
R321 1-247-879-91 CARBON 100K 5% 1/4W
R322 1-249-421-11 CARBON 2.2K 5% 1/4W
R323 1-249-421-11 CARBON 2.2K 5% 1/4W
R324 1-249-421-11 CARBON 2.2K 5% 1/4W
R325 1-247-879-91 CARBON 100K 5% 1/4W
R326 1-247-807-31 CARBON 100 5% 1/4W
R327 1-247-879-91 CARBON 100K 5% 1/4W
R328 1-247-879-91 CARBON 100K 5% 1/4W
R329 1-247-879-91 CARBON 100K 5% 1/4W
R339 1-247-895-00 CARBON 470K 5% 1/4W
R340 1-249-409-11 CARBON 220 5% 1/4W
R401 1-247-895-00 CARBON 470K 5% 1/4W
R402 1-247-843-11 CARBON 3.3K 5% 1/4W
R403 1-247-843-11 CARBON 3.3K 5% 1/4W
R406 1-247-895-00 CARBON 470K 5% 1/4W
R407 1-249-422-11 CARBON 2.7K 5% 1/4W
R409 1-247-847-91 CARBON 4.7K 5% 1/4W
R410 1-249-429-11 CARBON 10K 5% 1/4W
R411 1-249-429-11 CARBON 10K 5% 1/4W
R412 1-249-429-11 CARBON 10K 5% 1/4W
R413 1-247-895-00 CARBON 470K 5% 1/4W
R414 1-249-409-11 CARBON 220 5% 1/4W
R415 1-249-409-11 CARBON 220 5% 1/4W
R417 1-247-847-91 CARBON 4.7K 5% 1/4W
R421 1-247-879-91 CARBON 100K 5% 1/4W
R422 1-249-421-11 CARBON 2.2K 5% 1/4W
R423 1-249-421-11 CARBON 2.2K 5% 1/4W
R424 1-249-421-11 CARBON 2.2K 5% 1/4W
R425 1-247-879-91 CARBON 100K 5% 1/4W
MAIN
