Setup Menu 6-29
Chapter 6 Setup Menu
714 VIDEO ADJUST
RANGE
Select the variable range of the VIDEO and
CHROMA knobs when the PROCESS CONTROL
in the sub LCD menu is set to PANEL.
–3~+3 : –3 dB to +3 dB
WIDE: – ∞ to +3 dB
Item number Item name Settings
Menu items in the 700s, relating to video control (continued)
Items 715 to 721: Settings for controlling the video processing system according to the menu
settings.
Item number Item name Settings
715
VIDEO GAIN
CONTROL
Adjust the video output level.
Default value: 800H
716 CHROMA GAIN
CONTROL
Adjust the chroma output level.
Default value: 800H
717 CHROMA PHASE
CONTROL
Adjust the chroma phase.
Default value: 80H
718 SETUP LEVEL Adjust the setup level (black level).
Default value: 110H
719 SYSTEM PHASE
SYNC
Adjust the system sync phase.
Default value: 80H
720 SYSTEM PHASE SC Adjust the system sub-carrier phase.
Default value: 0H
721 Y/C DELAY For playback from an analog Betacam cassette,
adjust the Y/C delay.
Default value: 800H
Note
When you make settings for items 715
to 721, set the PROCESS CONTROL
in the sub LCD menu to SETUP.
When set to SETUP, all controls on
the front control panel and settings in
the sub LCD menu are disabled.
To Next Page
