HCD-CPX11
SERVICE POSITION OF THE CD MECHANISM DECK
CD mechanism deck
• Remove the front panel and the circuit boards once in order to remove the CD mechanism deck.
After removing the CDM, reassemble the panel and the circuit boards back to the original state.
Extension cable should be used.
(J-2501-248-A)(1.00mm/27P/300L)
COVER BOARD
cover board
• This is the board used to blind the slot. Do not remove.
