FIXING THE TC CABLES
PREVENTING THE SUB POWER CABLES FROM SAGGING DOWN
• To prevent cables from noise, fix the cables with the lead pin so that the cables do not contact with the flexible board.
lead pin
TC board
NG
• Be careful not to contact with the CD mechanism deck.
SUB POWER board
SUB POWER cabl
e
