8
HCD-CPX11
CAUTION SO THAT THE FLEXIBLE BOARD SHOULD NOT CONTACT WITH THE HEAT SINK
• When the flexible board is replaced, give the folding at the same position of the new flexible board with that of the old flexible board.
S-MASTER AMP board
