74
HCD-CPX11
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C872 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C882 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
< CONNECTOR >
CN850 1-564-505-21 PLUG, CONNECTOR 2P
CN870 1-564-505-11 PLUG, CONNECTOR 2P
< JACK >
J860 1-537-114-21 TERMINAL BOARD (SPEAKER)
< COIL >
L890 1-410-121-11 INDUCTOR 1.5mH
************************************************************
SUB PANEL BOARD
***************
< DIODE >
D870 8-719-046-36 DIODE SEL5921A-TP15 (CD NX)
< TRANSISTOR >
Q870 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R870 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R871 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R874 1-216-817-11 METAL CHIP 470 5% 1/10W
R875 1-216-817-11 METAL CHIP 470 5% 1/10W
R876 1-216-809-11 METAL CHIP 100 5% 1/10W
< SWITCH >
S816 1-762-875-21 SWITCH, KEYBOARD (CD NX)
S817 1-762-875-21 SWITCH, KEYBOARD ((CD) x)
************************************************************
SUB POWER BOARD
*****************
< CAPACITOR >
0 C991 1-113-925-11 CERAMIC 0.01uF 20% 250V
0 C992 1-113-925-11 CERAMIC 0.01uF 20% 250V
C993 1-126-768-11 ELECT 2200uF 20% 16V
C994 1-104-658-91 ELECT 100uF 20% 10V
< CONNECTOR >
CN990 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
< DIODE >
D990 8-719-988-61 DIODE 1SS355TE-17
D991 8-719-988-61 DIODE 1SS355TE-17
D992 6-500-522-31 DIODE 10EDB40-TB5
D993 6-500-522-31 DIODE 10EDB40-TB5
D994 6-500-522-31 DIODE 10EDB40-TB5
D995 6-500-522-31 DIODE 10EDB40-TB5
< IC >
IC991 6-703-627-01 IC NJU7201L40 (T3)
< TRANSISTOR >
Q990 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q991 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
< RESISTOR >
R991 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R992 1-216-845-11 METAL CHIP 100K 5% 1/10W
R993 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R994 1-216-845-11 METAL CHIP 100K 5% 1/10W
< RELAY >
0 RY990 1-755-467-11 RELAY (POWER)
0 RY991 1-755-467-11 RELAY (POWER)
< TRANSFORMER >
0 T991 1-437-676-11 TRANSFORMER, POWER (AEP, UK)
0 T991 1-437-677-11 TRANSFORMER, POWER (KR, AUS)
************************************************************
A-4750-369-A TC BOARD, COMPLETE
******************
< CAPACITOR >
C601 1-126-947-11 ELECT 47uF 20% 35V
C602 1-130-483-00 MYLAR 0.01uF 5% 50V
C604 1-130-495-00 MYLAR 0.1uF 5% 50V
C605 1-126-964-11 ELECT 10uF 20% 50V
C606 1-126-960-11 ELECT 1uF 20% 50V
C607 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C608 1-126-961-11 ELECT 2.2uF 20% 50V
C610 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C611 1-162-928-11 CERAMIC CHIP 120PF 5% 50V
C612 1-162-946-11 CERAMIC CHIP 27PF 5% 50V
C613 1-164-392-11 CERAMIC CHIP 390PF 5% 50V
C614 1-130-483-00 MYLAR 0.01uF 5% 50V
C630 1-126-933-11 ELECT 100uF 20% 16V
C632 1-126-964-11 ELECT 10uF 20% 50V
C633 1-126-964-11 ELECT 10uF 20% 50V
C634 1-126-964-11 ELECT 10uF 20% 50V
C635 1-126-960-11 ELECT 1uF 20% 50V
C639 1-126-964-11 ELECT 10uF 20% 50V
C640 1-126-947-11 ELECT 47uF 20% 35V
C641 1-126-961-11 ELECT 2.2uF 20% 50V
C642 1-137-150-11 FILM 0.01uF 5% 100V
C643 1-130-485-00 MYLAR 0.015uF 5% 50V
C644 1-130-481-00 MYLAR 0.0068uF 5% 50V
C645 1-130-481-00 MYLAR 0.0068uF 5% 50V
C646 1-130-486-00 MYLAR 0.018uF 5% 50V
C647 1-126-964-11 ELECT 10uF 20% 50V
C651 1-126-947-11 ELECT 47uF 20% 35V
C652 1-130-483-00 MYLAR 0.01uF 5% 50V
C654 1-130-495-00 MYLAR 0.1uF 5% 50V
C655 1-126-964-11 ELECT 10uF 20% 50V
C656 1-126-960-11 ELECT 1uF 20% 50V
C657 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C658 1-126-961-11 ELECT 2.2uF 20% 50V
C660 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C661 1-162-928-11 CERAMIC CHIP 120PF 5% 50V
SP SUB PANEL SUB POWER TC
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
