75
HCD-CPX11
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C662 1-162-946-11 CERAMIC CHIP 27PF 5% 50V
C663 1-164-392-11 CERAMIC CHIP 390PF 5% 50V
C664 1-130-483-00 MYLAR 0.01uF 5% 50V
C681 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
< CONNECTOR >
CN602 1-770-516-31 FFC/CONNECTOR, FPC (LIF (NON-ZIF)) 8P
CN603 1-784-780-11 CONNECTOR, FFC 19P
< DIODE >
D681 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC601 6-702-130-01 IC HA12237F
IC602 8-759-508-69 IC BA3126N
< SHORT >
JR602 1-216-296-11 SHORT CHIP 0
< JUMPER RESISTOR >
JW630 1-216-864-11 SHORT CHIP 0
< COIL >
L601 1-410-780-11 INDUCTOR 27mH
L651 1-410-780-11 INDUCTOR 27mH
< TRANSISTOR >
Q639 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q640 8-729-029-66 TRANSISTOR DTC114ESA
Q641 8-729-801-93 TRANSISTOR 2SD1387-3
Q642 8-729-142-46 TRANSISTOR 2SC2001-LK
Q643 8-729-142-46 TRANSISTOR 2SC2001-LK
Q680 8-729-029-66 TRANSISTOR DTC114ESA
Q681 8-729-029-40 TRANSISTOR DTA124ESA
Q691 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q692 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q693 8-729-140-04 TRANSISTOR 2SB1116A-L
Q694 8-729-116-57 TRANSISTOR 2SB1068-K
< RESISTOR >
R601 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R602 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R603 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R604 1-216-833-11 METAL CHIP 10K 5% 1/10W
R605 1-216-841-11 METAL CHIP 47K 5% 1/10W
R606 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R607 1-216-833-11 METAL CHIP 10K 5% 1/10W
R608 1-216-833-11 METAL CHIP 10K 5% 1/10W
R609 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R610 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R611 1-216-837-11 METAL CHIP 22K 5% 1/10W
R630 1-216-857-11 METAL CHIP 1M 5% 1/10W
R631 1-216-837-11 METAL CHIP 22K 5% 1/10W
R632 1-216-821-11 METAL CHIP 1K 5% 1/10W
R633 1-216-833-11 METAL CHIP 10K 5% 1/10W
R635 1-216-809-11 METAL CHIP 100 5% 1/10W
R640 1-216-833-11 METAL CHIP 10K 5% 1/10W
R641 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R642 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
0 R643 1-219-787-17 FUSIBLE 5.6 5% 1/4W
0 R644 1-219-787-17 FUSIBLE 5.6 5% 1/4W
R645 1-216-836-11 METAL CHIP 18K 5% 1/10W
R646 1-216-836-11 METAL CHIP 18K 5% 1/10W
R647 1-216-837-11 METAL CHIP 22K 5% 1/10W
R648 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R651 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R652 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R653 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R654 1-216-833-11 METAL CHIP 10K 5% 1/10W
R655 1-216-841-11 METAL CHIP 47K 5% 1/10W
R656 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R657 1-216-833-11 METAL CHIP 10K 5% 1/10W
R658 1-216-833-11 METAL CHIP 10K 5% 1/10W
R659 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R660 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R661 1-216-837-11 METAL CHIP 22K 5% 1/10W
R680 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R681 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R682 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R683 1-216-819-11 METAL CHIP 680 5% 1/10W
R684 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R685 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R686 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R687 1-216-841-11 METAL CHIP 47K 5% 1/10W
R688 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R689 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R690 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R691 1-216-833-11 METAL CHIP 10K 5% 1/10W
R692 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R693 1-216-841-11 METAL CHIP 47K 5% 1/10W
R694 1-216-837-11 METAL CHIP 22K 5% 1/10W
R695 1-216-833-11 METAL CHIP 10K 5% 1/10W
< VARIABLE RESISTOR >
RV603 1-241-768-11 RES, ADJ CERMET 220K
RV653 1-241-768-11 RES, ADJ CERMET 220K
< TRANSFORMER >
T601 1-423-980-11 TRANSFORMER, BIAS OSCILLATION
************************************************************
MISCELLANEOUS
***************
60 1-824-192-11 WIRE (FLAT TYPE) (8 CORE)
63 1-796-456-31 DECK, MECHANICAL (CMAL1Z-236A)
69 1-773-120-11 WIRE (FLAT TYPE) (19 CORE)
71 1-773-110-11 WIRE (FLAT TYPE) (19 CORE)
102 1-769-912-11 WIRE (FLAT TYPE) (9 CORE)
0 151 1-769-079-23 CORD, POWER (KR)
0 151 1-777-071-83 CORD, POWER (AEP, UK)
0 151 1-783-203-13 CORD, POWER (AUS)
155 1-777-353-11 FLAT CABLE (15 CORE) (AEP, UK)
155 1-824-486-11 WIRE (FLAT TYPE) (11 CORE) (KR, AUS)
TC
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
