HCD-DV2D
Pin No. Pin Name I/O Description
48 DSDA O DAC encoder data signal output
49 DSSTB O DAC encoder chip enable signal output
50 DSCK O DAC encoder clock signal output
51 XTO — Not used
52 E-STB O Chip enable output to the microphone echo
53 SDAT/ROM DA O Data output to the soundprocessor
54 SCK/ROM CK O Clock output to the soundprocessor
55 OPN O Loading motor FWD control signal output
56 CLS O Loading motor REV control signal output
57 E-CLK O Clock output to the microphone echo
58 E-DATA O Data output to the microphone echo
59 AMUTE O Audio line muting signal output
60 LED O LED control signal output
61 TUON O Tuner power supply control signal output
62 CD ON O CD power supply control signal output
63 RLY O Relay control signal output
64 PCON O Power supply control signal output
