Sony HCD-DV2D - Page 49

49
HCD-DV2D
Pin No. Pin Name I/O Description
110 MEMDA14 I/O Flash memory data bus
111 MEMDA3 I/O Flash memory data bus
112 MEMDA15 I/O Flash memory data bus
113 MEMDA4 I/O Flash memory data bus
114 GNDP — Ground terminal
115 MEMDA8 I/O Flash memory data bus
116 VDDP — Power supply terminal (+3.3V)
117 MEMDA5 I/O Flash memory data bus
118 MEMDA9 I/O Flash memory data bus
119 MEMDA6 I/O Flash memory data bus
120 MEMDA10 I/O Flash memory data bus
121 MEMDA7 I/O Flash memory data bus
122 MEMDA11 I/O Flash memory data bus
123 MFWOS2 I SCDVD signal input from the AV decoder
124 MEMCS1 — Not used
125 GNDP — Ground terminal
126 MEMCS0 — Not used
127 VDDP — Power supply terminal (+3.3V)
128 MEMRD I RD signal input from the AV decoder
129 MEMWR I WR signal input
130 VDDC — Power supply terminal (+1.8V)
131 MEMAD0 O Flash memory address bus
132 GNDC — Ground terminal
133 to 138 MEMAD1 to 6 O Flash memory address bus
139 GNDP — Ground terminal
140 MEMAD7 O Flash memory address bus
141 VDDP — Power supply terminal (+3.3V)
142 to 146 MEMAD8 to 12 O Flash memory address bus
147 to 150 MEMAD13 to 16 O Flash memory address bus
152 MEMAD14 O Flash memory address bus
153 VDDP — Power supply terminal (+3.3V)
154 MEMAD15 O Flash memory address bus
155 MEMAD16 O Flash memory address bus
156 VDDA — Power supply terminal (+1.8V)
157 RESET I Reset signal input
158 GNDA — Ground terminal
159 VDDP — Power supply terminal (+3.3V)
160 XO O System clock output (27MHz)
161 GCLKP I System clock input (27MHz)
162 GCLKA I System clock input (27MHz)
163 VDDADC — Power supply terminal (+3.3V)
164 SERADC2 — Not used
165 SERADC1 — Not used
166 SERADC0 — Not used
167 GNDADC — Ground terminal
168 DACGNDD — Ground terminal
169 CVBS/C/Y O Video signal output
170 CVBC/C O Video signal output
171 DACVDD — Power supply terminal (+5V)
