49
HCD-DX90
0251 A-4735-080-A BASE ASSY, OP (KSM-213DAP)
252 1-792-024-11 WIRE (FLAT TYPE) (16 CORE)
253 A-4724-934-A BD BOARD, COMPLETE
254 4-951-620-01 SCREW (2.6X8), +BVTP
Ref. No. Part No. Description Remarks
8-5. BASE UNIT SECTION (BU-K2BD38)
252
254
253
251
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
To Next Page
