Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-GN1300D
101101
R1540 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1541 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1542 1-216-839-11 METAL CHIP 33K 5% 1/10W
R1543 1-216-842-11 METAL CHIP 56K 5% 1/10W
R1544 1-216-814-11 METAL CHIP 270 5% 1/10W
R1545 1-216-814-11 METAL CHIP 270 5% 1/10W
R1546 1-216-842-11 METAL CHIP 56K 5% 1/10W
R1547 1-216-842-11 METAL CHIP 56K 5% 1/10W
R1548 1-216-815-11 METAL CHIP 330 5% 1/10W
R1549 1-216-842-11 METAL CHIP 56K 5% 1/10W
R1550 1-216-842-11 METAL CHIP 56K 5% 1/10W
R1551 1-216-842-11 METAL CHIP 56K 5% 1/10W
R1552 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1553 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1554 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1555 1-217-637-55 FUSIBLE 1 5% 1/4W
R1556 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R1559 1-216-809-11 METAL CHIP 100 5% 1/10W
R1560 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1566 1-216-842-11 METAL CHIP 56K 5% 1/10W
R1567 1-216-839-11 METAL CHIP 33K 5% 1/10W
R1568 1-216-838-11 METAL CHIP 27K 5% 1/10W
R1570 1-216-843-11 METAL CHIP 68K 5% 1/10W
R1571 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1572 1-245-711-31 CARBON 10 5% 1/2W
R1573 1-245-711-31 CARBON 10 5% 1/2W
R1574 1-245-711-31 CARBON 10 5% 1/2W
R1575 1-220-893-11 METAL 0.22 10% 5W
R1576 1-220-893-11 METAL 0.22 10% 5W
R1577 1-220-893-11 METAL 0.22 10% 5W
R1580 1-216-843-11 METAL CHIP 68K 5% 1/10W
R1584 1-216-843-11 METAL CHIP 68K 5% 1/10W
R1585 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1586 1-249-401-11 CARBON 47 5% 1/4W
R1587 1-249-401-11 CARBON 47 5% 1/4W
R1588 1-249-401-11 CARBON 47 5% 1/4W
R1592 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1593 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1594 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1595 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1596 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1610 1-216-811-11 METAL CHIP 150 5% 1/10W
R1611 1-216-811-11 METAL CHIP 150 5% 1/10W
R1612 1-216-811-11 METAL CHIP 150 5% 1/10W
R1613 1-216-811-11 METAL CHIP 150 5% 1/10W
R1614 1-216-811-11 METAL CHIP 150 5% 1/10W
R1615 1-216-811-11 METAL CHIP 150 5% 1/10W
R1616 1-216-811-11 METAL CHIP 150 5% 1/10W
R1617 1-216-811-11 METAL CHIP 150 5% 1/10W
R1618 1-216-811-11 METAL CHIP 150 5% 1/10W
R1619 1-216-811-11 METAL CHIP 150 5% 1/10W
R1620 1-216-811-11 METAL CHIP 150 5% 1/10W
R1621 1-216-811-11 METAL CHIP 150 5% 1/10W
< RELAY >
RY1500 1-755-307-21 RELAY
RY1501 1-755-307-21 RELAY
RY1502 1-755-307-21 RELAY
< TERMINAL >
TB1502 1-820-067-11 TERMINAL BOARD (SURROUND SPEAKER)
TB1503 1-820-067-11 TERMINAL BOARD
(CENTER SPEAKER, SUBWOOFER)
************************************************************
1-687-669-12 SW BOARD
**************
< SWITCH >
S751 1-786-514-11 SWITCH, LEVER (SLIDE) (OPEN)
************************************************************
TRANS BOARD
************
< CAPACITOR >
C1252 1-126-964-11 ELECT 10uF 20% 50V
C1253 1-128-563-11 ELECT 100uF 20% 100V
C1254 1-126-969-11 ELECT 220uF 20% 50V
C1255 1-126-767-11 ELECT 1000uF 20% 16V
< CONNECTOR >
CN1250 1-564-528-11 PLUG, CONNECTOR 13P
< DIODE >
D1250 6-501-785-01 DIODE MAZ8200GMLS0
D1251 6-501-788-01 DIODE MAZ8240G0LS0
D1252 6-500-522-21 DIODE 10EDB40-TB3
D1253 6-500-522-21 DIODE 10EDB40-TB3
D1254 6-500-522-21 DIODE 10EDB40-TB3
D1255 6-500-522-21 DIODE 10EDB40-TB3
D1256 6-500-522-21 DIODE 10EDB40-TB3
< FUSE >
0 F1271 1-523-087-11 FUSE 4A 250V (T4AL/250V)
0 F1281 1-523-084-11 FUSE 2A 250V (T4AL/250V)
< HOLDER, FUSE >
FH1230 1-533-217-41 HOLDER, FUSE
FH1232 1-533-217-41 HOLDER, FUSE
FH1240 1-533-217-41 HOLDER, FUSE
FH1242 1-533-217-41 HOLDER, FUSE
FH1250 1-533-217-41 HOLDER, FUSE
FH1252 1-533-217-41 HOLDER, FUSE
FH1260 1-533-217-41 HOLDER, FUSE
FH1262 1-533-217-41 HOLDER, FUSE
< TRANSISTOR >
Q1250 8-729-032-94 TRANSISTOR 2SD1859TV2Q
< RESISTOR >
R1250 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1251 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R1252 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R1271 1-219-124-55 FUSIBLE 0.68 5% 1/4W
************************************************************
TRANS
SURROUND
SW
Ver. 1.3
