Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-GN1300D
100
< SWITCH >
0 S1200 1-786-055-32 SELECTOR, VOLTAGE
< TRANSFORMER >
0 PT1200 1-443-928-21 TRANSFORMER, POWER (SUB)
************************************************************
SURROUND BOARD
****************
< CAPACITOR >
C1500 1-128-552-51 ELECT 47uF 20% 63V
C1501 1-128-552-51 ELECT 47uF 20% 63V
C1504 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1505 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1507 1-104-329-11 CERAMIC CHIP 0.1uF 10% 50V
C1508 1-104-329-11 CERAMIC CHIP 0.1uF 10% 50V
C1509 1-104-329-11 CERAMIC CHIP 0.1uF 10% 50V
C1510 1-104-329-11 CERAMIC CHIP 0.1uF 10% 50V
C1512 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1516 1-126-963-11 ELECT 4.7uF 20% 50V
C1517 1-126-947-11 ELECT 47uF 20% 35V
C1519 1-126-963-11 ELECT 4.7uF 20% 50V
C1520 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1521 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1522 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1523 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C1524 1-126-923-91 ELECT 220uF 20% 10V
C1525 1-126-923-91 ELECT 220uF 20% 10V
C1526 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C1527 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C1528 1-126-923-91 ELECT 220uF 20% 10V
C1529 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1530 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1531 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1532 1-126-963-11 ELECT 4.7uF 20% 50V
C1533 1-126-963-11 ELECT 4.7uF 20% 50V
C1534 1-126-963-11 ELECT 4.7uF 20% 50V
C1535 1-128-552-51 ELECT 47uF 20% 63V
C1536 1-128-552-51 ELECT 47uF 20% 63V
C1540 1-104-329-11 CERAMIC CHIP 0.1uF 10% 50V
C1541 1-104-329-11 CERAMIC CHIP 0.1uF 10% 50V
C1542 1-104-329-11 CERAMIC CHIP 0.1uF 10% 50V
C1543 1-104-329-11 CERAMIC CHIP 0.1uF 10% 50V
C1544 1-104-329-11 CERAMIC CHIP 0.1uF 10% 50V
C1545 1-104-329-11 CERAMIC CHIP 0.1uF 10% 50V
C1546 1-126-956-91 ELECT 0.1uF 20% 50V
C1547 1-126-956-91 ELECT 0.1uF 20% 50V
C1548 1-126-963-11 ELECT 4.7uF 20% 50V
C1549 1-126-963-11 ELECT 4.7uF 20% 50V
C1550 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1551 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1553 1-126-965-91 ELECT 22uF 20% 50V
C1555 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C1559 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
* CN1500 1-764-333-11 PLUG, CONNECTOR 10P
* CN1501 1-573-828-11 CONNECTOR, BOARD TO BOARD 14P
* CN1502 1-564-506-11 PLUG, CONNECTOR 3P
< DIODE >
D1500 6-500-335-01 DIODE MC2838-T112-1
D1502 6-501-817-01 DIODE MA2J1110GLS0
D1506 6-501-817-01 DIODE MA2J1110GLS0
D1507 6-501-817-01 DIODE MA2J1110GLS0
D1508 6-501-817-01 DIODE MA2J1110GLS0
D1509 6-501-817-01 DIODE MA2J1110GLS0
D1510 6-500-335-01 DIODE MC2838-T112-1
D1511 6-501-772-01 DIODE MAZ8130GMLS0
< IC >
IC1500 6-600-562-01 IC STK433-100-E
IC1502 6-713-972-01 IC STK433-290-E
< TRANSISTOR >
Q1500 8-729-924-99 TRANSISTOR 2SC3722K-E
Q1501 8-729-924-99 TRANSISTOR 2SC3722K-E
Q1502 8-729-924-99 TRANSISTOR 2SC3906K-T146E
Q1503 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1504 8-729-924-99 TRANSISTOR 2SC3722K-E
Q1505 8-729-924-99 TRANSISTOR 2SC3722K-E
Q1506 8-729-924-99 TRANSISTOR 2SC3722K-E
Q1507 8-729-924-99 TRANSISTOR 2SC3906K-T146E
Q1508 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1509 8-729-040-76 TRANSISTOR KTA1273-Y-AT
Q1511 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1512 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1513 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
< RESISTOR >
R1500 1-217-637-55 FUSIBLE 1 5% 1/4W
R1501 1-220-893-11 METAL 0.22 10% 5W
R1502 1-220-893-11 METAL 0.22 10% 5W
R1503 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1504 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1505 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1506 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1507 1-216-847-11 METAL CHIP 150K 5% 1/10W
R1508 1-216-847-11 METAL CHIP 150K 5% 1/10W
R1509 1-245-605-55 FUSIBLE 100 5% 1/4W
R1510 1-245-605-55 FUSIBLE 100 5% 1/4W
R1515 1-216-813-11 METAL CHIP 220 5% 1/10W
R1516 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1518 1-245-711-31 CARBON 10 5% 1/2W
R1519 1-245-711-31 CARBON 10 5% 1/2W
R1520 1-216-843-11 METAL CHIP 68K 5% 1/10W
R1522 1-216-843-11 METAL CHIP 68K 5% 1/10W
R1523 1-216-843-11 METAL CHIP 68K 5% 1/10W
R1524 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R1525 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1526 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1528 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1529 1-245-605-55 FUSIBLE 100 5% 1/4W
R1530 1-245-605-55 FUSIBLE 100 5% 1/4W
R1531 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1532 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1535 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1536 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1538 1-216-839-11 METAL CHIP 33K 5% 1/10W
R1539 1-216-839-11 METAL CHIP 33K 5% 1/10W
SURROUND
SUBTRANS
Ver. 1.3
