Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-GN1300D
9999
D929 6-502-795-02 DI 1L0351B12C0MXT03
D930 6-502-795-02 DI 1L0351B12C0MXT03
D931 6-502-795-02 DI 1L0351B12C0MXT03
< IC >
IC901 6-713-768-01 IC R8A66166SP
< RESISTOR >
R929
1-216-819-11 METAL CHIP 680 5% 1/10W
R931 1-216-819-11 METAL CHIP 680 5% 1/10W
R933 1-216-819-11 METAL CHIP 680 5% 1/10W
R935 1-216-819-11 METAL CHIP 680 5% 1/10W
R937 1-216-817-11 METAL CHIP 470 5% 1/10W
R938 1-216-817-11 METAL CHIP 470 5% 1/10W
R939 1-216-819-11 METAL CHIP 680 5% 1/10W
R940 1-216-819-11 METAL CHIP 680 5% 1/10W
R941 1-216-821-11 METAL CHIP 1K 5% 1/10W
R942 1-216-821-11 METAL CHIP 1K 5% 1/10W
R943 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R944 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R945 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R946 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R947 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R948 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R949 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R950 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R951 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R952 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R953 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R954 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R955 1-216-833-11 METAL CHIP 10K 5% 1/10W
R956 1-216-833-11 METAL CHIP 10K 5% 1/10W
R957 1-216-833-11 METAL CHIP 10K 5% 1/10W
R958 1-216-819-11 METAL CHIP 680 5% 1/10W
R960 1-216-819-11 METAL CHIP 680 5% 1/10W
R962 1-216-819-11 METAL CHIP 680 5% 1/10W
R964 1-216-819-11 METAL CHIP 680 5% 1/10W
R965 1-216-835-11 METAL CHIP 15K 5% 1/10W
R966 1-216-835-11 METAL CHIP 15K 5% 1/10W
R968 1-216-837-11 METAL CHIP 22K 5% 1/10W
R969 1-216-839-11 METAL CHIP 33K 5% 1/10W
R970 1-216-843-11 METAL CHIP 68K 5% 1/10W
R971 1-216-833-11 METAL CHIP 10K 5% 1/10W
R973 1-216-819-11 METAL CHIP 680 5% 1/10W
R975 1-216-819-11 METAL CHIP 680 5% 1/10W
R977 1-216-819-11 METAL CHIP 680 5% 1/10W
R979 1-216-819-11 METAL CHIP 680 5% 1/10W
R981 1-216-819-11 METAL CHIP 680 5% 1/10W
R985 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R986 1-216-809-11 METAL CHIP 100 5% 1/10W
R987 1-216-809-11 METAL CHIP 100 5% 1/10W
R988 1-216-809-11 METAL CHIP 100 5% 1/10W
R989 1-216-833-11 METAL CHIP 10K 5% 1/10W
R990 1-216-821-11 METAL CHIP 1K 5% 1/10W
< SWITCH >
S915 1-771-410-21 SWITCH, KEYBOARD (STOP)
S916 1-771-410-21 SWITCH, KEYBOARD (EQ BAND/MEMORY)
S917 1-771-410-21 SWITCH, KEYBOARD (PRESET + >)
S918 1-771-410-21 SWITCH, KEYBOARD (USER EQ)
S919 1-771-410-21 SWITCH, KEYBOARD (PRESET -.)
S920 1-771-410-21 SWITCH, KEYBOARD (NIGHT MODE)
S921 1-771-410-21 SWITCH, KEYBOARD (PLAY)
S922 1-771-410-21 SWITCH, KEYBOARD (SOUND FLASH)
S923 1-771-410-21 SWITCH, KEYBOARD (TUNING -tm)
S924 1-771-410-21 SWITCH, KEYBOARD (MUTING)
S925 1-771-410-21 SWITCH, KEYBOARD (RETURN)
S926 1-771-410-21 SWITCH, KEYBOARD (SOUND FIELD)
S927 1-771-410-21 SWITCH, KEYBOARD (DVD)
S928 1-771-410-21 SWITCH, KEYBOARD (GROOVE)
S929 1-771-410-21 SWITCH, KEYBOARD (USB)
S930 1-771-410-21 SWITCH, KEYBOARD (PRESET EQ)
S931 1-771-410-21 SWITCH, KEYBOARD (TV/SAT)
S932 1-771-410-21 SWITCH, KEYBOARD (TUNING +MT)
S933 1-771-410-21 SWITCH, KEYBOARD (SUBWOOFER ON/OFF)
S934 1-771-410-21 SWITCH, KEYBOARD (PAUSE)
S935 1-487-171-11 ROTARY ENCODER (MASTER_VOL)
S936 1-480-581-11 ROTARY ENCODER (OP_DIAL)
S937 1-771-410-21 SWITCH, TACTILE (SUBWOOFER LEVEL)
S938 1-771-410-21 SWITCH, TACTILE (ENTER)
S940 1-771-410-21 SWITCH, TACTILE
(TUNER AM (NO TAPE) TUNER/BAND (TAPE))
S941 1-771-410-21 SWITCH, TACTILE
(TUNER AM (NO TAPE) TAPE (TAPE)
S942 1-771-410-21 SWITCH, TACTILE (VIDEO)
S945 1-771-410-21 SWITCH, TACTILE (REC TO USB)
************************************************************
SUBTRANS BOARD
****************
< CAPACITOR >
C1200 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1201 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1203 1-126-942-61 ELECT 1000uF 20% 25V
C1204 1-126-965-91 ELECT 22uF 20% 50V
C1205 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1206 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN1200 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
CN1201 1-568-106-11 PIN, CONNECTOR (3.96mm PITCH) 4P
CN1203 1-785-316-11 PIN, CONNECTOR (STRAIGHT) 4P
< DIODE >
D1200 6-501-817-01 DIODE MA2J1110GLS0
D1201 6-500-848-01 DIODE MC2840-T112-1
D1202 6-500-848-01 DIODE MC2840-T112-1
D1203 6-500-335-01 DIODE MC2838-T112-1
< TRANSISTOR >
Q1200 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
< RESISTOR >
R1201 1-216-819-11 METAL CHIP 680 5% 1/10W
R1202 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1205 1-216-845-11 METAL CHIP 100K 5% 1/10W
< RELAY >
0 RY1200 1-755-334-11 RELAY, AC POWER
STR SUBTRANS
Ver. 1.3
