Sony HCD-GN1300D - Electrical Parts List - Connectors, Diodes, ICs, Transistors, Resistors (MIC DVD;Motor(LD);Motor(TB);Sensor;SW Boards)

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-GN1300D
98
C1128 1-124-257-00 ELECT 2.2uF 20% 50V
C1129 1-124-257-00 ELECT 2.2uF 20% 50V
C1130 1-124-257-00 ELECT 2.2uF 20% 50V
C1131 1-124-257-00 ELECT 2.2uF 20% 50V
< CONNECTOR >
CN1100 1-785-331-11 PIN, CONNECTOR (LIGHT ANGLE) 5P
< DIODE >
D1000 6-500-848-01 DIODE MC2840-T112-1
D1001 6-500-848-01 DIODE MC2840-T112-1
D1003 6-500-848-01 DIODE MC2840-T112-1
D1101 6-501-730-01 DIODE MAZ8051GMLS0
< IC >
IC1000 8-759-278-58 IC NJM4558V-TE2
IC1100 6-709-116-01 IC TC9488FG
IC1101 8-759-278-58 IC NJM4558V-TE2
< JACK >
J1000 1-764-592-11 JACK 3P
(VIDEO INPUT VIDEO/AUDIO L/AUDIO R)
J1002 1-822-757-11 JACK (LARGE TYPE) (MIC 1)
J1003 1-822-757-11 JACK (LARGE TYPE) (MIC 2)
< JUMPER RESISTOR >
JR1000 1-216-296-11 SHORT CHIP 0
JR1001 1-216-296-11 SHORT CHIP 0
JR1021 1-216-864-11 SHORT CHIP 0
< RESISTOR >
R1000 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1001 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1003 1-216-849-11 METAL CHIP 220K 5% 1/10W
R1004 1-216-849-11 METAL CHIP 220K 5% 1/10W
R1009 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1010 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1011 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1019 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1020 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1021 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1022 1-216-864-11 SHORT CHIP 0
R1023 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1024 1-216-838-11 METAL CHIP 27K 5% 1/10W
R1025 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1026 1-216-864-11 SHORT CHIP 0
R1100 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1101 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1102 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1103 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1104 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1105 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1106 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1107 1-216-835-11 METAL CHIP 15K 5% 1/10W
R1108 1-216-864-11 SHORT CHIP 0
R1109 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R1110 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R1111 1-216-834-11 METAL CHIP 12K 5% 1/10W
R1114 1-216-815-11 METAL CHIP 330 5% 1/10W
R1115 1-216-815-11 METAL CHIP 330 5% 1/10W
R1118 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1119 1-216-809-11 METAL CHIP 100 5% 1/10W
R1120 1-216-809-11 METAL CHIP 100 5% 1/10W
R1121 1-216-809-11 METAL CHIP 100 5% 1/10W
R1124 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1126 1-216-864-11 SHORT CHIP 0
R1128 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1129 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1130 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1131 1-218-344-11 METAL CHIP 7.5K 5% 1/10W
R1132 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R1133 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R1134 1-218-344-11 METAL CHIP 7.5K 5% 1/10W
************************************************************
1-687-133-12 MOTOR (LD) BOARD
*****************
************************************************************
1-687-134-12 MOTOR (TB) BOARD
*****************
< CONNECTOR >
CN742 1-784-727-11 CONNECTOR, FFC 5P
************************************************************
1-687-132-12 SENSOR BOARD
**************
<IC>
IC731 6-600-564-01 IC RPI-579N1
< CONNECTOR >
CN731 1-785-329-21 PIN, CONNECTOR (LIGHT ANGLE) 3P
************************************************************
STR BOARD
**********
< CAPACITOR >
C920 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C921 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C922 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C923 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C925 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C926 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN903D 1-785-329-11 PIN, CONNECTOR (LIGHT ANGLE) 3P
< DIODE >
D919 8-719-060-27 DIODE SLR-325MCT31
D920 6-502-795-02 DI 1L0351B12C0MXT03
D921 6-502-795-02 DI 1L0351B12C0MXT03
D922 6-502-795-02 DI 1L0351B12C0MXT03
D923 6-502-795-02 DI 1L0351B12C0MXT03
D924 6-502-795-02 DI 1L0351B12C0MXT03
D925 6-502-795-02 DI 1L0351B12C0MXT03
D926 6-502-795-02 DI 1L0351B12C0MXT03
D927 6-502-795-02 DI 1L0351B12C0MXT03
D928 6-502-795-02 DI 1L0351B12C0MXT03
MIC DVD MOTOR(LD) SENSOR STRMOTOR(TB)
Ver. 1.3
