• Circuit Boards Location
MOTOR DRIVE board
(Included in METER DISPLAY ASSY)
MAIN board
DVD MIC VR board
MIC DVD board
CD SW board
STR board
DISPLAY board
SW (Meter) board
(Included in METER DISPLAY ASSY)
LED(GTH) board
(Included in METER DISPLAY ASSY)
USB DVD board
HP board
TUNER PACK
FRONT board
SURROUND board
DMB18 board
DRIVER board
SENSOR board
MOTOR (TB) board
MOTOR (LD) board
SUBTRANS board
TRANS board
KARAOKE SCORING board
CONNECTOR board
VIDEO board
SW board
