• Waveforms
– DMB18 Board –
– MAIN Board –
– VIDEO Board –
1.7 Vp-p
3.3 Vp-p
5 V/DIV, 10 msec/DIV
5V/DIV, 50 nsec/DIV
11 m sec
200 n sec
20V/DIV, 5 msec/DIV
60 Vp-p
32 m sec
 IC100 RB XC OUT
 IC100 RE X-OUT
 CN150  EH+
1.0 Vp-p
H
0.5 V/DIV, 20 msec/DIV
1.3 Vp-p
H
0.5 V/DIV, 20 msec/DIV
1.6 Vp-p
H
0.5 V/DIV, 20 msec/DIV
1.6 Vp-p
H
0.5 V/DIV, 20 msec/DIV
0.8 Vp-p
H
0.5 V/DIV, 20 msec/DIV
2.0 Vp-p
H
1 V/DIV, 20 msec/DIV
2.6 Vp-p
H
1 V/DIV, 20 msec/DIV
1 V/DIV, 20 msec/DIV
0.8 Vp-p
H
0.5 V/DIV, 20 msec/DIV
1.5 Vp-p
H
1 V/DIV, 20 msec/DIV
1 V/DIV, 20 msec/DIV
2.0 Vp-p
H
1 V/DIV, 20 msec/DIV
1 V/DIV, 20 msec/DIV
2.0 Vp-p
H
1.5 Vp-p
H
2.6 Vp-p
H
 IC1700  CIN
 IC1700  CVBSIN
 IC1700  YIN
RB IC1700 XE CVBSOUT
RT IC1700 XI C OUT
RE IC1701  OUT
 IC1700  CYIN
 IC1700 RT CBIN
 IC1700 RG CRIN
 IC1700 RI CROUT
 IC1700 RL CBOUT
 IC1700 X CYOUT
 IC1700 XB YOUT
 IC4602  BICK
 IC4602  MCLK
3.3 Vp-p
4.0 Vp-p
41 nsec
0.33 msec
2V/DIV, 0.1 msec/DIV
2V/DIV, 20 nsec/DIV
 IC102  DVDRFIP
0.6 Vp-p
0.2V/DIV, 500 nsec/DIV
 IC102 F FED
0.1V/DIV, 0.5 msec/DIV
0.1 Vp-p
 IC102 FB TEO
0.1 V/DIV, 0.5 msec/DIV
0.1 Vp-p
 IC102 XTALO
238
40 nsec
1.1 Vp-p
0.5V/DIV, 20 nsec/DIV
