Sony HCD-GN1300D - Electrical Parts List - DMB18 Board (Continued)

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-GN1300D
8787
< IC >
IC101 (Not supplied) IC MX29LV320DBTI-70-CBA-0901CE
(EA, E15, E4)
IC101 (Not supplied) IC MX29LV320DBTI-70-CBA-0901GA
(SP, MY, PH)
IC102 6-713-715-01 IC CXD9894R-A
IC103 (Not supplied) IC S-24CS64A01-J8T1G
IC104 6-711-090-01 IC K4S641632K-UC60T
IC105 6-702-302-01 IC TK11133CSCL-G
IC107 6-702-302-01 IC TK11133CSCL-G
IC110 6-707-739-01 IC MM1661JTRE
IC201 6-704-524-01 IC FAN8036L
IC3601 6-710-840-01 IC AK5358AET-E2
IC4602 6-713-827-01 IC AK4359AEF-E2
< COIL >
L3602
1-469-555-21 INDUCTOR 10uH
< TRANSISTOR >
Q101 6-550-008-01 TRANSISTOR UM6K1N-TN
Q102 6-550-653-01 TRANSISTOR QST8TR
Q103 8-729-027-52 TRANSISTOR DTC124EKA-T146
< RESISTOR >
R101 1-216-809-11 METAL CHIP 100 5% 1/10W
R102 1-216-864-11 SHORT CHIP 0
R103 1-218-864-11 METAL CHIP 5.1K 0.5% 1/10W
R105 1-216-833-11 METAL CHIP 10K 5% 1/10W
R106 1-216-833-11 METAL CHIP 10K 5% 1/10W
R107 1-216-833-11 METAL CHIP 10K 5% 1/10W
R108 1-216-857-11 METAL CHIP 1M 5% 1/10W
R109 1-216-864-11 SHORT CHIP 0
R110 1-216-841-11 METAL CHIP 47K 5% 1/10W
R111 1-216-809-11 METAL CHIP 100 5% 1/10W
R112 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R113 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R114 1-216-845-11 METAL CHIP 100K 5% 1/10W
R115 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R116 1-216-821-11 METAL CHIP 1K 5% 1/10W
R117 1-216-841-11 METAL CHIP 47K 5% 1/10W
R118 1-216-801-11 METAL CHIP 22 5% 1/10W
R120 1-216-801-11 METAL CHIP 22 5% 1/10W
R121 1-216-801-11 METAL CHIP 22 5% 1/10W
R123 1-216-864-11 SHORT CHIP 0
R124 1-216-841-11 METAL CHIP 47K 5% 1/10W
R125 1-216-805-11 METAL CHIP 47 5% 1/10W
R132 1-216-845-11 METAL CHIP 100K 5% 1/10W
R133 1-216-864-11 SHORT CHIP 0
R134 1-216-809-11 METAL CHIP 100 5% 1/10W
R135 1-216-821-11 METAL CHIP 1K 5% 1/10W
R136 1-216-835-11 METAL CHIP 15K 5% 1/10W
R137 1-216-809-11 METAL CHIP 100 5% 1/10W
R138 1-216-809-11 METAL CHIP 100 5% 1/10W
R139 1-216-864-11 SHORT CHIP 0
R140 1-216-821-11 METAL CHIP 1K 5% 1/10W
R141 1-216-855-11 METAL CHIP 680K 5% 1/10W
R142 1-216-845-11 METAL CHIP 100K 5% 1/10W
R146 1-216-805-11 METAL CHIP 47 5% 1/10W
R151 1-216-833-11 METAL CHIP 10K 5% 1/10W
R152 1-216-864-11 SHORT CHIP 0
R153 1-216-864-11 SHORT CHIP 0
R154 1-216-864-11 SHORT CHIP 0
R155 1-216-864-11 SHORT CHIP 0
R156 1-216-809-11 METAL CHIP 100 5% 1/10W
R159 1-216-805-11 METAL CHIP 47 5% 1/10W
R160 1-216-805-11 METAL CHIP 47 5% 1/10W
R161 1-216-805-11 METAL CHIP 47 5% 1/10W
R171 1-216-809-11 METAL CHIP 100 5% 1/10W
R175 1-216-864-11 SHORT CHIP 0
R183 1-216-805-11 METAL CHIP 47 5% 1/10W
R184 1-216-805-11 METAL CHIP 47 5% 1/10W
R185 1-216-805-11 METAL CHIP 47 5% 1/10W
R189 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R190 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R191 1-216-821-11 METAL CHIP 1K 5% 1/10W
R192 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R193 1-216-821-11 METAL CHIP 1K 5% 1/10W
R195 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R197 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R198 1-216-809-11 METAL CHIP 100 5% 1/10W
R204 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R205 1-216-833-11 METAL CHIP 10K 5% 1/10W
R206 1-216-833-11 METAL CHIP 10K 5% 1/10W
R207 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R208 1-216-839-11 METAL CHIP 33K 5% 1/10W
R209 1-216-839-11 METAL CHIP 33K 5% 1/10W
R210 1-216-841-11 METAL CHIP 47K 5% 1/10W
R212 1-216-833-11 METAL CHIP 10K 5% 1/10W
R213 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R214 1-216-835-11 METAL CHIP 15K 5% 1/10W
R215 1-216-834-11 METAL CHIP 12K 5% 1/10W
R216 1-216-834-11 METAL CHIP 12K 5% 1/10W
R219 1-216-838-11 METAL CHIP 27K 5% 1/10W
R220 1-216-833-11 METAL CHIP 10K 5% 1/10W
R221 1-218-889-11 METAL CHIP 56K 0.5% 1/10W
R223 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R224 1-216-833-11 METAL CHIP 10K 5% 1/10W
R225 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R226 1-218-889-11 METAL CHIP 56K 0.5% 1/10W
R230 1-218-893-11 METAL CHIP 82K 0.5% 1/10W
R231 1-218-875-11 METAL CHIP 15K 0.5% 1/10W
R232 1-218-877-11 METAL CHIP 18K 0.5% 1/10W
R233 1-218-883-11 METAL CHIP 33K 0.5% 1/10W
R234 1-216-833-11 METAL CHIP 10K 5% 1/10W
R246 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R247 1-216-821-11 METAL CHIP 1K 5% 1/10W
R321 1-216-864-11 SHORT CHIP 0
R408 1-216-295-91 SHORT CHIP 0
R501 1-216-864-11 SHORT CHIP 0
R502 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
R503 1-216-864-11 SHORT CHIP 0
R505 1-216-809-11 METAL CHIP 100 5% 1/10W
R506 1-216-809-11 METAL CHIP 100 5% 1/10W
R507 1-216-809-11 METAL CHIP 100 5% 1/10W
R508 1-216-809-11 METAL CHIP 100 5% 1/10W
R509 1-216-809-11 METAL CHIP 100 5% 1/10W
R510 1-216-809-11 METAL CHIP 100 5% 1/10W
R511 1-216-809-11 METAL CHIP 100 5% 1/10W
R512 1-216-809-11 METAL CHIP 100 5% 1/10W
DMB18
Ver. 1.3
Note: IC101 and IC103 on the DMB18 board cannot exchange with single.
When these parts on the DMB18 board are damaged, exchange the
entire mounted board.
