Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-GN1300D
88
R514 1-216-809-11 METAL CHIP 100 5% 1/10W
R515 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R516 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R519 1-216-864-11 SHORT CHIP 0
R521 1-216-833-11 METAL CHIP 10K 5% 1/10W
R522 1-216-833-11 METAL CHIP 10K 5% 1/10W
R523 1-216-833-11 METAL CHIP 10K 5% 1/10W
R524 1-216-833-11 METAL CHIP 10K 5% 1/10W
R532 1-216-864-11 SHORT CHIP 0
R536 1-216-864-11 SHORT CHIP 0
R730 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R781 1-216-833-11 METAL CHIP 10K 5% 1/10W
R782 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1101 1-218-841-11 METAL CHIP 560 0.5% 1/10W
R1102 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R1103 1-216-809-11 METAL CHIP 100 5% 1/10W
R1104 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1108 1-216-864-11 SHORT CHIP 0
R1110 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R1114 1-481-216-21 FERRITE, EMI (SMD) (1608)
R1115 1-216-864-11 SHORT CHIP 0
R1116 1-216-864-11 SHORT CHIP 0
R1117 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1129 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1133 1-216-864-11 SHORT CHIP 0
R1134 1-216-864-11 SHORT CHIP 0
R1135 1-216-864-11 SHORT CHIP 0
R1145 1-216-864-11 SHORT CHIP 0
R1150 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1151 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1152 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1154 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1155 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1156 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R1157 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R1163 1-216-864-11 SHORT CHIP 0
R1164 1-216-864-11 SHORT CHIP 0
R1167 1-216-864-11 SHORT CHIP 0
R1168 1-216-817-11 METAL CHIP 470 5% 1/10W
R1173 1-216-864-11 SHORT CHIP 0
R1176 1-216-864-11 SHORT CHIP 0
R1177 1-216-864-11 SHORT CHIP 0
R1178 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1179 1-216-809-11 METAL CHIP 100 5% 1/10W
R1180 1-216-809-11 METAL CHIP 100 5% 1/10W
R1182 1-216-864-11 SHORT CHIP 0
R1184 1-216-809-11 METAL CHIP 100 5% 1/10W
R1185 1-216-809-11 METAL CHIP 100 5% 1/10W
R1188 1-216-864-11 SHORT CHIP 0
R1189 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1190 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1191 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1192 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1193 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1194 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1196 1-216-864-11 SHORT CHIP 0
R1197 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1198 1-216-809-11 METAL CHIP 100 5% 1/10W
R1200 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1203 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V
R2504 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3504 1-216-809-11 METAL CHIP 100 5% 1/10W
R3601 1-216-809-11 METAL CHIP 100 5% 1/10W
R3602 1-216-809-11 METAL CHIP 100 5% 1/10W
R3603 1-216-809-11 METAL CHIP 100 5% 1/10W
R3605 1-216-805-11 METAL CHIP 47 5% 1/10W
R3606 1-216-805-11 METAL CHIP 47 5% 1/10W
R3611 1-216-809-11 METAL CHIP 100 5% 1/10W
R3612 1-216-864-11 SHORT CHIP 0
R3613 1-216-809-11 METAL CHIP 100 5% 1/10W
R3621 1-216-809-11 METAL CHIP 100 5% 1/10W
R3801 1-216-864-11 SHORT CHIP 0
R3803 1-216-864-11 SHORT CHIP 0
R3804 1-216-864-11 SHORT CHIP 0
R4403 1-216-864-11 SHORT CHIP 0 (EXCEPT EA)
R4404 1-216-864-11 SHORT CHIP 0 (EXCEPT EA)
R4423 1-216-864-11 SHORT CHIP 0 (EXCEPT EA)
R4424 1-216-864-11 SHORT CHIP 0 (EXCEPT EA)
R4443 1-216-864-11 SHORT CHIP 0 (EXCEPT EA)
R4444 1-216-864-11 SHORT CHIP 0 (EXCEPT EA)
R4463 1-216-864-11 SHORT CHIP 0 (EXCEPT EA)
R4464 1-216-864-11 SHORT CHIP 0 (EXCEPT EA)
R4701 1-216-864-11 SHORT CHIP 0
R4702 1-216-864-11 SHORT CHIP 0
R4703 1-216-864-11 SHORT CHIP 0
R4704 1-216-864-11 SHORT CHIP 0
R4705 1-216-864-11 SHORT CHIP 0
R4706 1-216-864-11 SHORT CHIP 0
R4804 1-216-864-11 SHORT CHIP 0
R4806 1-216-805-11 METAL CHIP 47 5% 1/10W
R4807 1-216-805-11 METAL CHIP 47 5% 1/10W
R5004 1-216-864-11 SHORT CHIP 0 (EA, E15, E4)
R5014 1-216-864-11 SHORT CHIP 0 (SP, MY, PH)
< COMPOSITION CIRCUIT BLOCK >
RB103 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB104 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB105 1-234-371-21 RES, NETWORK 47 (1005X4)
RB106 1-234-371-21 RES, NETWORK 47 (1005X4)
RB107 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB108 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB109 1-234-370-21 RES, NETWORK 22 (1005X4)
RB110 1-234-370-21 RES, NETWORK 22 (1005X4)
RB111 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB112 1-234-370-21 RES, NETWORK 22 (1005X4)
RB113 1-234-370-21 RES, NETWORK 22 (1005X4)
RB114 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB115 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB121 1-234-378-21 RES, NETWORK 10K (1005X4)
< VIBRATOR >
* X101 1-814-031-11 VIBRATOR, CRYSTAL(27MHz)
************************************************************
A-1103-756-B DRIVER BOARD, COMPLETE
***********************
< CAPACITOR >
C715 1-126-933-11 ELECT 100uF 20% 16V
C731 1-126-964-11 ELECT 10uF 20% 50V
C735 1-164-159-21 CERAMIC 0.1uF 50V
DRIVERDMB18
Ver. 1.3
