Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-GN1300D
8989
C736 1-164-159-21 CERAMIC 0.1uF 50V
C737 1-164-159-21 CERAMIC 0.1uF 50V
C741 1-114-708-41 CERAMIC 0.01uF 10% 50V
C751 1-114-708-41 CERAMIC 0.01uF 10% 50V
C752 1-164-159-21 CERAMIC 0.1uF 50V
< CONNECTOR >
CN701 1-784-735-11 CONNECTOR, FFC 13P
CN702 1-784-766-11 CONNECTOR, FFC 5P
CN703 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
CN704 1-785-328-11 PIN, CONNECTOR (LIGHT ANGRE) 2P
< DIODE >
D701 8-719-921-42 DIODE MTZJ-5.1A
D711 8-719-109-69 DIODE RD3.6ESB2
< IC >
IC701 8-759-598-69 IC BA6956AN
IC712 8-759-598-69 IC BA6956AN
< TRANSISTOR >
Q731 8-729-029-66 TRANSISTOR DTC114ESA
< RESISTOR >
R701 1-249-413-11 CARBON 470 5% 1/4W
R702 1-247-807-31 CARBON 100 5% 1/4W
R711 1-249-417-11 CARBON 1K 5% 1/4W
R712 1-249-425-11 CARBON 4.7K 5% 1/4W
R713 1-249-433-11 CARBON 22K 5% 1/4W
R721 1-249-425-11 CARBON 4.7K 5% 1/4W
R722 1-249-425-11 CARBON 4.7K 5% 1/4W
R723 1-249-425-11 CARBON 4.7K 5% 1/4W
R731 1-247-807-31 CARBON 100 5% 1/4W
R732 1-249-429-11 CARBON 10K 5% 1/4W
R733 1-249-417-11 CARBON 1K 5% 1/4W
R734 1-249-430-11 CARBON 12K 5% 1/4W
R736 1-249-412-11 CARBON 390 5% 1/4W
R751 1-249-425-11 CARBON 4.7K 5% 1/4W
************************************************************
DVD MIC VR BOARD
****************
< RESISTOR >
R1116 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1117 1-216-864-11 SHORT CHIP 0
R1122 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R1123 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
< VARIABLE RESISTOR >
RV1100 1-227-452-11 RES, VAR, CARBON 50K (MIC 1 LEVEL)
RV1101 1-227-452-11 RES, VAR, CARBON 50K (MIC 2 LEVEL)
RV1102 1-227-452-11 RES, VAR, CARBON 50K (ECHO LEVEL)
************************************************************
FRONT BOARD
************
< CAPACITOR >
C1308 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C1313 1-126-961-11 ELECT 2.2uF 20% 50V
C1314 1-104-658-91 ELECT 100uF 20% 10V
C1316 1-128-582-11 ELECT 10uF 20% 100V
C1318 1-100-153-91 CERAMIC CHIP 220PF 5% 100V
C1319 1-164-730-11 CERAMIC CHIP 0.0012uF 10% 50V
C1320 1-126-947-11 ELECT 47uF 20% 35V
C1321 1-164-730-11 CERAMIC CHIP 0.0012uF 10% 50V
C1322 1-100-153-91 CERAMIC CHIP 220PF 5% 100V
C1323 1-126-947-11 ELECT 47uF 20% 35V
C1324 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C1325 1-126-963-11 ELECT 4.7uF 20% 50V
C1326 1-126-963-11 ELECT 4.7uF 20% 50V
C1329 1-126-965-91 ELECT 22uF 20% 50V
C1332 1-130-777-00 MYLAR 0.1uF 5% 100V
C1331 1-128-582-11 ELECT 10uF 20% 100V
C1333 1-130-777-00 MYLAR 0.1uF 5% 100V
C1334 1-127-815-11 ELECT (BLOCK) 3300uF 20% 100V
C1335 1-127-815-11 ELECT (BLOCK) 3300uF 20% 100V
C1336 1-119-940-51 ELECT 4700uF 20% 50V
C1337 1-130-777-00 MYLAR 0.1uF 5% 100V
C1338 1-130-777-00 MYLAR 0.1uF 5% 100V
C1339 1-119-940-51 ELECT 4700uF 20% 50V
C1340 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C1341 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C1342 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C1343 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50
< CONNECTOR >
CN1302 1-573-825-11 CONNECTOR, FFC 11P
CN1303 1-573-829-11 CONNECTOR, FFC 15P
< DIODE >
D1302 6-501-817-01 DIODE MA2J1110GLS0
D1304 6-501-178-01 DIODE UDZW-TE17-15B
D1306 6-501-178-01 DIODE UDZW-TE17-15B
D1308 6-501-817-01 DIODE MA2J1110GLS0
D1309 6-500-334-01 DIODE MC2836-T112-1
D1310 6-501-754-01 DIODE MAZ8091G0LS0
D1312 6-501-817-01 DIODE MA2J1110GLS0
D1313 8-719-073-32 DIODE D25XB60
D1314 8-719-073-32 DIODE D25XB60
D1315 6-500-335-01 DIODE MC2838-T112-1
< IC >
IC1302 6-600-169-01 IC STK412-240M-E
< JACK >
JK1301 1-820-067-11 TERMINAL BOARD (FRONT SPEAKER)
< TRANSISTOR >
Q1301 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1302 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1303 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1304 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1305 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q1306 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1307 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1308 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1309 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1310 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1312 8-729-924-99 TRANSISTOR 2SC3722K-E
Q1313 8-729-924-99 TRANSISTOR 2SC3722K-E
DVD MIC VR
DRIVER
FRONT
