Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-GN1300D
90
Q1314 8-729-821-00 TRANSISTOR 2SA1207
< RESISTOR >
R1306 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1307 1-216-813-11 METAL CHIP 220 5% 1/10W
R1313 1-215-872-11 METAL OXIDE 3.3K 5% 1W
R1314 1-215-872-11 METAL OXIDE 3.3K 5% 1W
R1315 1-217-637-55 FUSIBLE 1 5% 1/4W
R1317 1-216-842-11 METAL CHIP 56K 5% 1/10W
R1318 1-216-842-11 METAL CHIP 56K 5% 1/10W
R1319 1-216-843-11 METAL CHIP 68K 5% 1/10W
R1320 1-245-711-31 CARBON 10 5% 1/2W
R1321 1-245-711-31 CARBON 10 5% 1/2W
R1322 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1323 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1324 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1325 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1326 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1327 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1328 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1329 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1330 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1331 1-245-605-55 FUSIBLE 100 5% 1/4W
R1332 1-216-842-11 METAL CHIP 56K 5% 1/10W
R1333 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1334 1-216-842-11 METAL CHIP 56K 5% 1/10W
R1335 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1336 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R1337 1-216-842-11 METAL CHIP 56K 5% 1/10W
R1338 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1339 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R1340 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1341 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1342 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1343 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1344 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1345 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1348 1-245-605-55 FUSIBLE 100 5% 1/4W
R1349 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1350 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1351 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1352 1-216-839-11 METAL CHIP 33K 5% 1/10W
R1354 1-216-843-11 METAL CHIP 68K 5% 1/10W
R1355 1-216-843-11 METAL CHIP 68K 5% 1/10W
R1356 1-216-843-11 METAL CHIP 68K 5% 1/10W
R1358 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1359 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1360 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1361 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1362 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1363 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1364 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1365 1-216-849-11 METAL CHIP 220K 5% 1/10W
R1367 1-216-849-11 METAL CHIP 220K 5% 1/10W
R1369 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1370 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1372 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1374 1-234-499-21 ENCAPSULATED COMPONENT
R1375 1-234-499-21 ENCAPSULATED COMPONENT
R1395 1-246-024-21 METAL CHIP 150 5% 1/2W
R1396 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1397 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
< RELAY >
RY1301 1-755-307-21 RELAY
< THERMISTOR >
TH1301 1-804-045-11 THERMISTOR
************************************************************
HP BOARD
*********
< CAPACITOR >
C1060 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1061 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1062 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< DIODE >
D1050 6-500-848-01 DIODE MC2840-T112-1
< FERRITE BEAD >
FB1001 1-469-116-21 FERRITE, EMI (SMD) (1608)
FB1002 1-469-116-21 FERRITE, EMI (SMD) (1608)
FB1003 1-469-116-21 FERRITE, EMI (SMD) (1608)
< JACK >
J1005 1-794-702-11 JACK, HEADPHONE (PHONES)
************************************************************
KARAOKE SCORING BOARD
***********************
< CAPACITOR >
C2000 1-104-658-91 ELECT 100uF 20% 10V
C2001 1-126-947-11 ELECT 47uF 20% 35V
C2002 1-126-947-11 ELECT 47uF 20% 35V
C2004 1-126-961-11 ELECT 2.2uF 20% 50V
C2005 1-126-947-11 ELECT 47uF 20% 35V
C2006 1-126-960-11 ELECT 1uF 20% 50V
C2007 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C2008 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C2009 1-126-947-11 ELECT 47uF 20% 35V
C2010 1-126-961-11 ELECT 2.2uF 20% 50V
C2011 1-126-947-11 ELECT 47uF 20% 35V
C2013 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C2015 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C2016 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< DIODE >
D2000 6-501-817-01 DIODE MA2J1110GLS0
D2001 6-501-817-01 DIODE MA2J1110GLS0
D2002 6-501-817-01 DIODE MA2J1110GLS0
D2003 6-501-817-01 DIODE MA2J1110GLS0
D2006 6-501-817-01 DIODE MA2J1110GLS0
D2007 1-216-295-91 SHORT CHIP 0
D2008 6-501-817-01 DIODE MA2J1110GLS0
< IC >
IC2000 8-759-545-66 IC NJM3414AMP (TE2)
HP
FRONT
KARAOKE SCORING
