Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-GNV99D/GNV111D
R1147 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1148 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1160 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R1161 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1162 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R1163 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1164 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1165 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1166 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1167 1-216-814-11 METAL CHIP 270 5% 1/10W
R1175 1-216-817-11 METAL CHIP 470 5% 1/10W
R1176 1-216-819-11 METAL CHIP 680 5% 1/10W
R1177 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1178 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1179 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1180 1-216-814-11 METAL CHIP 270 5% 1/10W
R1183 1-216-808-11 METAL CHIP 82 5% 1/10W
R1186 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1187 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1188 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1189 1-216-801-11 METAL CHIP 22 5% 1/10W
R1194 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1195 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1197 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1198 1-216-821-11 METAL CHIP 1K 5% 1/10W
< SWITCH >
S900 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
S901 1-762-875-21 SWITCH, KEYBOARD (PROGRESSIVE)
S902 1-762-875-21 SWITCH, KEYBOARD (EQ BAND)
S903 1-762-875-21 SWITCH, KEYBOARD (DIRECTION)
S904 1-762-875-21 SWITCH, KEYBOARD (REC PAUSE/START)
S910 1-762-875-21 SWITCH, KEYBOARD (VIDEO)
S911 1-762-875-21 SWITCH, KEYBOARD (TV/SAT)
S912 1-762-875-21 SWITCH, KEYBOARD (CD SYNC)
S913 1-762-875-21 SWITCH, KEYBOARD (bB)
S914 1-762-875-21 SWITCH, KEYBOARD (X)
S915 1-762-875-21 SWITCH, KEYBOARD (x)
S916 1-479-229-11 ROTARY ENCODER (PRESET)
S917 1-771-963-11 SWITCH, ROTARY (TUNING)
S918 1-762-875-21 SWITCH, KEYBOARD (TAPE A/B)
S919 1-762-875-21 SWITCH, KEYBOARD (TUNER/BAND)
S920 1-762-875-21 SWITCH, KEYBOARD (DVD)
S925 1-762-875-21 SWITCH, KEYBOARD (`/1)
S927 1-762-875-21 SWITCH, KEYBOARD (AMP MENU)
S928 1-762-875-21 SWITCH, KEYBOARD (ILLUMINATION)
S929 1-762-875-21 SWITCH, KEYBOARD (SOUND FIELD)
S930 1-762-875-21 SWITCH, KEYBOARD (GROOVE)
S931 1-762-875-21 SWITCH, KEYBOARD (SOUND FLASH)
S932 1-762-875-21 SWITCH, KEYBOARD (ENTER)
S970 1-418-725-51 ENCODER, ROTARY (12 TYPE)
(MASTER VOLUME)
< VIBRATOR >
X901 1-781-282-51 VIBRATOR, CERAMIC (4 MHz)
*************************************************************
A-1089-510-A PRIMARY BOARD, COMPLETE
(EXCEPT TH, MX, AUS)
A-1089-525-A PRIMARY BOARD, COMPLETE (MX, AUS)
A-1114-764-A PRIMARY BOARD, COMPLETE (TH)
**************
< CAPACITOR >
C1201 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1202 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1204 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1206 1-126-916-11 ELECT 1000uF 20% 6.3V
< CONNECTOR >
CN1200 1-785-329-11 PIN, CONNECTOR (LIGHT ANGLE) 3P
CN1202 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
CN1204 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
(TH, MX, AUS)
CN1204 1-568-106-11 PIN, CONNECTOR (3.96mm PITCH) 4P
(EXCEPT TH, MX, AUS)
< DIODE >
D1200 8-719-988-61 DIODE 1SS355TE-17
< JUMPER RESISTOR >
JR1202 1-216-864-11 SHORT CHIP 0
< COIL >
L1201 1-410-666-31 INDUCTOR 18uH
< TRANSISTOR >
Q1200 8-729-120-28 TRANSISTOR 2SC1623-L5L6
< RESISTOR >
R1200 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1201 1-216-845-11 METAL CHIP 100K 5% 1/10W
< RELAY >
0 RY1200 1-755-299-11 RELAY
< SWITCH >
0 S1200 1-771-291-31 SWITCH, POWER (VOLTAGE SELECTOR)
(EXCEPT TH, MX, AUS)
*************************************************************
1-687-132-12 SENSOR BOARD
*************
< CONNECTOR >
CN731 1-785-329-21 PIN, CONNECTOR (LIGHT ANGLE) 3P
< IC >
IC731 6-600-022-01 IC RPI-576
*************************************************************
PANEL PRIMARY
Ver. 1.1
SENSOR
To Next Page
