99
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-GNV99D/GNV111D
1-687-669-12 SW BOARD
*********
S751 1-786-514-11 SWITCH, LEVER (SLIDE) (OPEN)
*************************************************************
TRANS BOARD
************
1-533-217-41 HOLDER, FUSE
< CAPACITOR >
C1262 1-126-964-11 ELECT 10uF 20% 50V
C1263 1-126-968-11 ELECT 100uF 20% 50V
C1292 1-128-576-11 ELECT 100uF 20% 63V
< CONNECTOR >
* CN1212 1-564-522-11 PLUG, CONNECTOR 7P
* CN1213 1-564-523-11 PLUG, CONNECTOR 8P
< DIODE >
D1264 8-719-071-83 DIODE HZU36BTRF
D1292 6-500-522-21 DIODE 10EDB40-TB3
< TRANSISTOR >
Q1264 8-729-024-93 TRANSISTOR 2SB1565E
< RESISTOR >
R1262 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R1263 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R1264 1-216-821-11 METAL CHIP 1K 5% 1/10W
0 R1292 1-219-124-11 FUSIBLE 0.68 5% 1/4W
*************************************************************
A-1101-214-A VIDEO BOARD, COMPLETE (EXCEPT EA, TH, AUS)
A-1119-149-A VIDEO BOARD, COMPLETE (TH)
A-1124-694-A VIDEO BOARD, COMPLETE (EA, AUS)
************
< CAPACITOR >
C800 1-126-960-11 ELECT 1uF 20% 50V
C801 1-126-960-11 ELECT 1uF 20% 50V
C802 1-126-960-11 ELECT 1uF 20% 50V
C803 1-126-965-91 ELECT 22uF 20% 50V
C804 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C805 1-126-960-11 ELECT 1uF 20% 50V
C806 1-126-960-11 ELECT 1uF 20% 50V
C807 1-126-960-11 ELECT 1uF 20% 50V
C808 1-104-658-91 ELECT 100uF 20% 10V
C809 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C810 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C811 1-126-916-11 ELECT 1000uF 20% 6.3V
C812 1-126-916-11 ELECT 1000uF 20% 6.3V
C813 1-126-916-11 ELECT 1000uF 20% 6.3V
C814 1-126-916-11 ELECT 1000uF 20% 6.3V
C815 1-126-916-11 ELECT 1000uF 20% 6.3V
C816 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C817 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C818 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C819 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C820 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C821 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C822 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C823 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C824 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C825 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C826 1-126-964-11 ELECT 10uF 20% 50V
C827 1-126-964-11 ELECT 10uF 20% 50V
C829 1-126-916-11 ELECT 1000uF 20% 6.3V
C830 1-104-658-91 ELECT 100uF 20% 10V
C831 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
CN800 1-564-707-11 PIN, CONNECTOR (SMALL TYPE) 5P
CN801 1-779-281-11 CONNECTOR, FFC (LIF (NON-ZIF)) 13P
CN802 1-785-328-11 PIN, CONNECTOR (LIGHT ANGRE) 2P
< FERRITE BEAD >
FB800 1-216-864-11 SHORT CHIP 0
FB801 1-216-864-11 SHORT CHIP 0
FB802 1-216-864-11 SHORT CHIP 0
FB803 1-216-864-11 SHORT CHIP 0
FB804 1-216-864-11 SHORT CHIP 0
FB805 1-216-864-11 SHORT CHIP 0
FB806 1-216-864-11 SHORT CHIP 0
< IC >
IC800 8-759-295-90 IC NJM2244M-TE2
IC801 6-705-602-01 IC MM1623BFBE
< JACK >
J800 1-817-449-11 JACK, PIN 3P (COMPONENT VIDEO OUT)
J801 1-537-943-11 TERMINAL, S (S VIDEO OUT)
J802 1-774-227-11 JACK, PIN 1P (VIDEO OUT)
< JUMPER RESISTOR >
JR800 1-216-864-11 SHORT CHIP 0
JR801 1-216-864-11 SHORT CHIP 0
JR802 1-216-864-11 SHORT CHIP 0 (EXCEPT EA, AUS)
JR802 1-469-147-21 FERRITE, EMI (SMD) (EA, AUS)
JR803 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
JR804 1-216-864-11 SHORT CHIP 0
< COIL >
L801 1-414-183-41 INDUCTOR 10uH
< TRANSISTOR >
Q800 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R800 1-216-809-11 METAL CHIP 100 5% 1/10W
R801 1-216-833-11 METAL CHIP 10K 5% 1/10W
R802 1-218-285-11 METAL CHIP 75 5% 1/10W
R803 1-218-285-11 METAL CHIP 75 5% 1/10W
R804 1-218-285-11 METAL CHIP 75 5% 1/10W
R805 1-218-285-11 METAL CHIP 75 5% 1/10W
TRANS VIDEOSW
Ver. 1.1
