HCD-GNZ5D
SECTION 9
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
A-1109-313-A AUDIO BOARD, COMPLETE
**********************
< CAPACITOR >
C201 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C202 1-104-658-11 ELECT 100uF 20% 10V
C203 1-104-658-11 ELECT 100uF 20% 10V
C204 1-104-658-11 ELECT 100uF 20% 10V
C205 1-104-658-11 ELECT 100uF 20% 10V
C211 1-126-964-11 ELECT 10uF 20% 50V
C213 1-126-964-11 ELECT 10uF 20% 50V
C214 1-126-964-11 ELECT 10uF 20% 50V
C218 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C219 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C220 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C221 1-126-964-11 ELECT 10uF 20% 50V
C222 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C223 1-126-964-11 ELECT 10uF 20% 50V
C224 1-137-194-81 FILM 0.47uF 5% 50V
C225 1-137-194-81 FILM 0.47uF 5% 50V
C226 1-126-960-11 ELECT 1uF 20% 50V
C228 1-126-964-11 ELECT 10uF 20% 50V
C236 1-130-491-00 MYLAR 0.047uF 5% 50V
C237 1-126-964-11 ELECT 10uF 20% 50V
C239 1-126-959-11 ELECT 0.47uF 20% 50V
C251 1-126-964-11 ELECT 10uF 20% 50V
C253 1-126-964-11 ELECT 10uF 20% 50V
C254 1-126-964-11 ELECT 10uF 20% 50V
C256 1-126-964-11 ELECT 10uF 20% 50V
C258 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C259 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C260 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C261 1-126-964-11 ELECT 10uF 20% 50V
C262 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C263 1-126-964-11 ELECT 10uF 20% 50V
C264 1-137-194-81 FILM 0.47uF 5% 50V
C265 1-137-194-81 FILM 0.47uF 5% 50V
C266 1-126-960-11 ELECT 1uF 20% 50V
C268 1-126-964-11 ELECT 10uF 20% 50V
C273 1-126-964-11 ELECT 10uF 20% 50V
C274 1-126-960-11 ELECT 1uF 20% 50V
C281 1-126-964-11 ELECT 10uF 20% 50V
C282 1-104-658-11 ELECT 100uF 20% 10V
C283 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C285 1-126-961-11 ELECT 2.2uF 20% 50V
C286 1-104-658-11 ELECT 100uF 20% 10V
C311 1-126-964-11 ELECT 10uF 20% 50V
C312 1-126-964-11 ELECT 10uF 20% 50V
C316 1-126-964-11 ELECT 10uF 20% 50V
C321 1-126-964-11 ELECT 10uF 20% 50V
C322 1-126-964-11 ELECT 10uF 20% 50V
C323 1-216-864-11 SHORT CHIP 0
C325 1-126-964-11 ELECT 10uF 20% 50V
C351 1-126-964-11 ELECT 10uF 20% 50V
C352 1-126-964-11 ELECT 10uF 20% 50V
C356 1-126-964-11 ELECT 10uF 20% 50V
C361 1-126-964-11 ELECT 10uF 20% 50V
C362 1-126-964-11 ELECT 10uF 20% 50V
C363 1-216-864-11 SHORT CHIP 0
C365 1-126-964-11 ELECT 10uF 20% 50V
C367 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C368 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C601 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C602 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C603 1-136-155-00 FILM 0.015uF 5% 50V
C604 1-126-965-11 ELECT 22uF 20% 50V
C605 1-106-375-12 MYLAR 0.022uF 5% 200V
C611 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C612 1-100-670-11 CERAMIC CHIP 4.7uF 20% 16V
C613 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C614 1-126-963-11 ELECT 4.7uF 20% 50V
C615 1-137-150-11 FILM 0.01uF 5% 100V
C616 1-126-947-11 ELECT 47uF 20% 35V
C617 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C618 1-126-964-11 ELECT 10uF 20% 50V
C619 1-136-497-81 FILM 0.1uF 5% 50V
C620 1-126-960-11 ELECT 1uF 20% 50V
C621 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C622 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C623 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C624 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C651 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C652 1-100-670-11 CERAMIC CHIP 4.7uF 20% 16V
C653 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C654 1-126-963-11 ELECT 4.7uF 20% 50V
C655 1-137-150-11 FILM 0.01uF 5% 100V
C656 1-126-947-11 ELECT 47uF 20% 35V
C657 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C658 1-126-964-11 ELECT 10uF 20% 50V
• Abbreviation
E3 : 240 V AC area in E model
E12 : 220 – 240 V AC area in E model
E13 : 220 – 230 V AC area in E model
E15 : Iran model
PH : Philippine model
