77
HCD-GNZ5D
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C3721 1-162-977-11 CERAMIC CHIP 0.0018uF 10% 50V
C3722 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C3723 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C3724 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C3771 1-162-977-11 CERAMIC CHIP 0.0018uF 10% 50V
C3772 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C3773 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C3774 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C3781 1-162-977-11 CERAMIC CHIP 0.0018uF 10% 50V
C3782 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C3783 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C3784 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C3801 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C3802 1-117-370-11 CERAMIC CHIP 10uF 10V
C3803 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C3804 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C3805 1-126-208-21 ELECT CHIP 47uF 20% 4V
< CONNECTOR >
CN101 1-815-763-32 CONNECTOR, FFC/FPC 24P
* CN105 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P
CN106 1-793-989-21 CONNECTOR, FFC/FPC 13P
* CN201 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P
CN301 1-784-365-21 CONNECTOR, FFC/FPC 5P
CN302 1-784-376-11 CONNECTOR, FFC/FPC 17P
CN401 1-779-993-11 PIN, CONNECTOR (PWB) 5P
< DIODE >
D1001 8-719-058-24 DIODE RB501V-40TE-17
D3501 6-501-193-01 DIODE 1SS355WTE-17
D3502 6-501-193-01 DIODE 1SS355WTE-17
< FERRITE BEAD >
FB111 1-414-226-21 INDUCTOR, FERRITE BEAD
FB112 1-414-226-21 INDUCTOR, FERRITE BEAD
FB113 1-414-226-21 INDUCTOR, FERRITE BEAD
FB114 1-414-226-21 INDUCTOR, FERRITE BEAD
FB115 1-414-226-21 INDUCTOR, FERRITE BEAD
FB401 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB402 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB403 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB404 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB405 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB406 1-469-324-21 FERRITE, EMI (SMD) (2012)
< FILTER >
FL101 1-234-177-21 FILTER, CHIP EMI
FL104 1-234-177-21 FILTER, CHIP EMI
FL105 1-234-177-21 FILTER, CHIP EMI
FL106 1-234-177-21 FILTER, CHIP EMI
FL107 1-234-177-21 FILTER, CHIP EMI
FL108 1-234-177-21 FILTER, CHIP EMI
FL401 1-234-177-21 FILTER, CHIP EMI
FL402 1-233-893-21 FILTER, CHIP EMI
FL403 1-234-177-21 FILTER, CHIP EMI
< IC >
IC101 6-805-764-01 IC MX29LV320ABTC65-CBA4-0503CE
(EXCEPT PH)
IC101 6-805-765-01 IC MX29LV320ABTC65-CBA4-0503GA (PH)
IC102 6-707-535-01 IC CXD9849R
IC103 (not supplied) IC BR24L64F-WE2
IC104 6-705-929-01 IC K4S641632H-UC75T
IC105 6-702-302-01 IC TK11133CSCL-G
IC106 6-708-153-01 IC PQ018EN01ZPH
IC107 6-702-302-01 IC TK11133CSCL-G
IC201 6-704-524-01 IC FAN8036L
IC301 6-704-222-01 IC AK4358VQ-L
IC3711 8-759-359-49 IC NJM3414AV(TE2)
IC3771 8-759-359-49 IC NJM3414AV(TE2)
< TRANSISTOR >
Q101 6-550-008-01 FET UM6K1N-TN
Q102 6-550-653-01 FET QST8TR
Q103 8-729-901-00 TRANSISTOR DTC124EK
Q3801 8-729-230-49 TRANSISTOR 2SC2712-YG
< RESISTOR >
R101 1-216-809-11 METAL CHIP 100 5% 1/10W
R104 1-216-864-11 SHORT CHIP 0
R105 1-216-833-11 METAL CHIP 10K 5% 1/10W
R106 1-216-833-11 METAL CHIP 10K 5% 1/10W
R107 1-216-833-11 METAL CHIP 10K 5% 1/10W
R108 1-216-857-11 METAL CHIP 1M 5% 1/10W
R109 1-216-864-11 SHORT CHIP 0
R110 1-216-841-11 METAL CHIP 47K 5% 1/10W
R111 1-216-809-11 METAL CHIP 100 5% 1/10W
R112 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R113 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R114 1-216-845-11 METAL CHIP 100K 5% 1/10W
R115 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R116 1-216-821-11 METAL CHIP 1K 5% 1/10W
R117 1-216-841-11 METAL CHIP 47K 5% 1/10W
R118 1-216-801-11 METAL CHIP 22 5% 1/10W
R120 1-216-801-11 METAL CHIP 22 5% 1/10W
R121 1-216-801-11 METAL CHIP 22 5% 1/10W
R123 1-216-864-11 SHORT CHIP 0
R124 1-216-841-11 METAL CHIP 47K 5% 1/10W
R126 1-216-864-11 SHORT CHIP 0
R127 1-216-809-11 METAL CHIP 100 5% 1/10W
R136 1-216-835-11 METAL CHIP 15K 5% 1/10W
R138 1-216-845-11 METAL CHIP 100K 5% 1/10W
R141 1-218-916-11 METAL CHIP 750K 0.5% 1/10W
R142 1-216-845-11 METAL CHIP 100K 5% 1/10W
R143 1-469-116-21 FERRITE, EMI (SMD) (1608)
R144 1-216-864-11 SHORT CHIP 0
R146 1-216-805-11 METAL CHIP 47 5% 1/10W
R151 1-216-805-11 METAL CHIP 47 5% 1/10W
R152 1-216-864-11 SHORT CHIP 0
R153 1-216-805-11 METAL CHIP 47 5% 1/10W
R155 1-216-805-11 METAL CHIP 47 5% 1/10W
R160 1-216-805-11 METAL CHIP 47 5% 1/10W
R161 1-216-809-11 METAL CHIP 100 5% 1/10W
DMB11
Ver. 1.1
New part of EEP ROM (IC103) on the DMB11 board cannot be used. Therefore,
if the mounted DMB11 board (A-1109-317-A, etc.) is replaced, exchange new
EEP ROM (IC103) with that used before the replacement.
