SERVICE MANUAL
E Model
HCD-GNZ7D/GNZ8D/GNZ9D
Australian Model
HCD-GNZ9D
Ver. 1.1 2005. 12
9-879-622-81
HCD-GNZ7D/GNZ8D/GNZ9D
SUPPLEMENT-1
File this supplement with the service manual.
Subject: Board changed to DMB11 board from DMB10 board
The DMB10 board has been changed to the DMB11 board in production.
This service manual supplement-1 describes only the printed wiring board for
the DMB11 board.
The schematic diagram and electrical parts list of the DMB11 board are added
in the DMB10 section of the original service manual.
