Sony HCD-GNZ8D - Front Panel Section; DVD Block Section

13
HCD-GNZ7D/GNZ8D/GNZ9D
3-3. FRONT PANEL SECTION
7 CN601 (3P)
qs CN1002 (4P)
5 CN751 (10P)
6 CN602 (8P)
4 CN752 (29 core
)
1 CN005 (13 core)
3 CN203 (9P)
2 CN102 (13 core)
9 screw
(+BVTP 3
× 10)
0 screw
(+BVTP 3
× 10)
qa
8
four screws (+BVTT 3 × 6)
qd front panel section
3-4. DVD BLOCK SECTION
2 three screws
(+BVTT 3
× 6)
1 three screws
(+BVTT 3
× 10)
3 two screws
(+BVTT 3
× 10)
4
5
CN301 (17 core)
6 CN851 (12P)
7 DVD block section
