HCD-GNZ7D/GNZ8D/GNZ9D
SECTION 9
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference
number, please include the board.
A-1095-768-A AUDIO BOARD, COMPLETE
(GNZ9D:EXCEPT E2,TH)
A-1095-769-A AUDIO BOARD, COMPLETE (GNZ8D:EXCEPT TH)
A-1095-770-A AUDIO BOARD, COMPLETE
(GNZ7D:EXCEPT E2,TH)
A-1111-480-A AUDIO BOARD, COMPLETE (GNZ9D:TH)
A-1111-481-A AUDIO BOARD, COMPLETE (GNZ8D:TH)
A-1111-482-A AUDIO BOARD, COMPLETE (GNZ7D:TH)
A-1122-987-A AUDIO BOARD, COMPLETE (GNZ9D:E2)
A-1122-988-A AUDIO BOARD, COMPLETE (GNZ7D:E2)
**********************
< CAPACITOR >
C201 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C202 1-104-658-11 ELECT 100uF 20% 10V
C203 1-104-658-11 ELECT 100uF 20% 10V
C204 1-104-658-11 ELECT 100uF 20% 10V
C205 1-104-658-11 ELECT 100uF 20% 10V
C211 1-126-964-11 ELECT 10uF 20% 50V
C212 1-126-964-11 ELECT 10uF 20% 50V
C213 1-126-964-11 ELECT 10uF 20% 50V
C214 1-126-964-11 ELECT 10uF 20% 50V
C215 1-126-964-11 ELECT 10uF 20% 50V
C217 1-126-964-11 ELECT 10uF 20% 50V
C218 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C219 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C220 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C221 1-126-964-11 ELECT 10uF 20% 50V
C222 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C223 1-126-964-11 ELECT 10uF 20% 50V
C224 1-137-194-81 FILM 0.47uF 5% 50V
C225 1-137-194-81 FILM 0.47uF 5% 50V
C226 1-126-960-11 ELECT 1uF 20% 50V
C228 1-126-964-11 ELECT 10uF 20% 50V
C229 1-110-518-11 ELECT 10uF 20% 100V
C232 1-126-960-11 ELECT 1uF 20% 50V
C233 1-136-497-81 FILM 0.1uF 5% 50V
(GNZ7D)
C234 1-137-190-11 FILM 0.22uF 5% 50V
(GNZ7D)
C235 1-126-964-11 ELECT 10uF 20% 50V
C236 1-130-491-00 MYLAR 0.047uF 5% 50V
C237 1-126-964-11 ELECT 10uF 20% 50V
C239 1-126-959-11 ELECT 0.47uF 20% 50V
C240 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C241 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C245 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C246 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C251 1-126-964-11 ELECT 10uF 20% 50V
C252 1-126-964-11 ELECT 10uF 20% 50V
C253 1-126-964-11 ELECT 10uF 20% 50V
C254 1-126-964-11 ELECT 10uF 20% 50V
C255 1-126-964-11 ELECT 10uF 20% 50V
C256 1-126-964-11 ELECT 10uF 20% 50V
C257 1-126-964-11 ELECT 10uF 20% 50V
C258 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C259 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C260 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C261 1-126-964-11 ELECT 10uF 20% 50V
C262 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C263 1-126-964-11 ELECT 10uF 20% 50V
C264 1-137-194-81 FILM 0.47uF 5% 50V
C265 1-137-194-81 FILM 0.47uF 5% 50V
C266 1-126-960-11 ELECT 1uF 20% 50V
C268 1-126-964-11 ELECT 10uF 20% 50V
C269 1-110-518-11 ELECT 10uF 20% 100V
C273 1-126-964-11 ELECT 10uF 20% 50V
C274 1-126-960-11 ELECT 1uF 20% 50V
C281 1-126-964-11 ELECT 10uF 20% 50V
C282 1-104-658-11 ELECT 100uF 20% 10V
C283 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C285 1-126-961-11 ELECT 2.2uF 20% 50V
C286 1-104-658-11 ELECT 100uF 20% 10V
C301 1-104-658-11 ELECT 100uF 20% 10V
(GNZ8D/GNZ9D)
C302 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(GNZ8D/GNZ9D)
C303 1-104-658-11 ELECT 100uF 20% 10V
(GNZ8D/GNZ9D)
C304 1-104-658-11 ELECT 100uF 20% 10V
(GNZ8D/GNZ9D)
C306 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(GNZ7D)
C307 1-126-923-11 ELECT 220uF 20% 10V
(GNZ7D)
C311 1-126-964-11 ELECT 10uF 20% 50V
C312 1-126-964-11 ELECT 10uF 20% 50V
• Abbreviation
E2 : 120 V AC area in E model
E3 : 240 V AC area in E model
E12 : 220-240 V AC area in E model
E13 : 220-230 V AC area in E model
E15 : Iran model
E51 : Chilean and Peruvian model
AUS: Australian model
EA : Saudi Arabia model
PH : Philippine model
SP : Singapore model
MX : Mexican model
TH : Thai model
