Sony HCD-GNZ8D - DVD Mechanism Block, Video Board, DMB10 Board; Pick-Up Unit

18
HCD-GNZ7D/GNZ8D/GNZ9D
3-14. PICK-UP UNIT
3-13. DVD MECHANISM BLOCK, VIDEO BOARD, DMB10 BOARD
qd screw
(+BVTP 3 × 8)
qh bracket (DVD)
qf screw
(+BVTP 3 × 8)
qg
3
two screws
(+BVTT 3 × 6)
6 three screws
(+BVTT 3 × 6
)
0 two screws
(+BVTT 3 × 6)
qa two screws
(+BVTT 3 × 6)
5 VIDEO board
7 REINFORCE (CDM) board
qs DMB10 board
8 CN201 (6P)
9 CN101 (24 core)
qj DVD mechanism block
2 CN401 (5P)
1 CN801 (13P)
4 claw
2 two insulator screws
4 two insulators
5 two insulators
3 two insulator screws
6 pick-up unit
7 holder (310)
1 floating screw
(+PTPWH M2.6
)
Note : Be short-circuited of the land of optical pick-up when CN101
is done in pulling out.
