HCD-GNZ7D/GNZ8D/GNZ9D
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C656 1-126-947-11 ELECT 47uF 20% 35V
C657 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C658 1-126-964-11 ELECT 10uF 20% 50V
C659 1-136-497-81 FILM 0.1uF 5% 50V
C721 1-107-696-11 ELECT 47uF 20% 16V
C725 1-107-696-11 ELECT 47uF 20% 16V
C726 1-107-696-11 ELECT 47uF 20% 16V
C728 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C753 1-119-939-51 ELECT 6800uF 20% 35V
C763 1-111-235-61 ELECT 10000uF 20% 25V
C764 1-126-963-11 ELECT 4.7uF 20% 50V
C765 1-126-961-11 ELECT 2.2uF 20% 50V
C771 1-126-956-11 ELECT 0.1uF 20% 50V
C772 1-126-923-11 ELECT 220uF 20% 10V
C775 1-216-864-11 SHORT CHIP 0 (GNZ7D/GNZ8D)
C776 1-216-864-11 SHORT CHIP 0
C778 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(GNZ7D)
C781 1-126-963-11 ELECT 4.7uF 20% 50V
(GNZ9D)
C783 1-162-974-11 CERAMIC CHIP 0.01uF 50V
(GNZ9D)
C784 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
(GNZ9D)
C785 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
(GNZ9D)
C791 1-126-963-11 ELECT 4.7uF 20% 50V
C793 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C794 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C795 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
< CONNECTOR >
CN201 1-573-847-11 CONNECTOR, BOARD TO BOARD 15P
CN202 1-573-847-11 CONNECTOR, BOARD TO BOARD 15P
CN203 1-785-321-11 PIN, CONNECTOR (STRAIGHT) 9P
CN301 1-779-283-11 CONNECTOR, FFC (LIF(NON-ZIF)) 15P
(GNZ8D/GNZ9D)
CN301 1-779-285-11 CONNECTOR, FFC (LIF(NON-ZIF)) 17P
(GNZ7D)
CN302 1-564-707-11 PIN, CONNECTOR (SMALL TYPE) 5P
(GNZ8D/GNZ9D)
* CN303 1-564-708-11 PIN, CONNECTOR (SMALL TYPE) 6P (GNZ9D)
* CN601 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
* CN602 1-564-710-11 PIN, CONNECTOR (SMALL TYPE) 8P
* CN745 1-564-517-11 PLUG, CONNECTOR 2P (GNZ9D)
CN751 1-785-322-11 PIN, CONNECTOR (STRAIGHT) 10P
CN752 1-784-788-11 CONNECTOR, FFC 27P
CN753 1-568-828-11 CONNECTOR, FFC 9P
* CN754 1-564-518-11 PLUG, CONNECTOR 3P
* CN755 1-564-706-11 PIN, CONNECTOR (SMALL TYPE) 4P
< DIODE >
D201 8-719-988-61 DIODE 1SS355TE-17
D202 8-719-988-61 DIODE 1SS355TE-17
D235 8-719-988-61 DIODE 1SS355TE-17
D271 6-500-848-01 DIODE MC2840-T112-1
D301 8-719-988-61 DIODE 1SS355TE-17 (GNZ8D/GNZ9D)
D722 8-719-988-61 DIODE 1SS355TE-17
D725 8-719-988-61 DIODE 1SS355TE-17
D726 8-719-988-61 DIODE 1SS355TE-17
D727 8-719-988-61 DIODE 1SS355TE-17
D728 8-719-988-61 DIODE 1SS355TE-17
D751 8-719-028-23 DIODE D3SBA20-4101
D753 6-500-335-01 DIODE MC2838-T112-1
D761 8-719-028-23 DIODE D3SBA20-4101
D762 8-719-988-61 DIODE 1SS355TE-17
D763 6-500-335-01 DIODE MC2838-T112-1
D771 6-500-522-21 DIODE 10EDB40-TB3
D781 8-719-988-61 DIODE 1SS355TE-17 (GNZ9D)
D783 8-719-083-63 DIODE UDZSTE-1713B (GNZ9D)
D791 8-719-988-61 DIODE 1SS355TE-17
D792 8-719-069-56 DIODE UDZSTE-176.2B
D793 8-719-069-56 DIODE UDZSTE-176.2B
< GROUND TERMINAL >
EPT751 1-537-771-21 TERMINAL BOARD, GROUND
< FERRITE BEAD >
FB301 1-216-295-11 SHORT CHIP 0 (GNZ7D:EXCEPT TH)
FB301 1-500-445-21 FERRITE, EMI (SMD) (2012) (GNZ7D:TH)
< IC >
IC201 6-705-667-01 IC M61537FP-RF0G
IC203 6-703-610-01 IC RT8H015C-T112-1
IC301 6-703-651-11 IC M61530FP-D60G (GNZ8D/GNZ9D)
IC303 8-759-710-97 IC NJM4565M-D (GNZ9D)
IC305 8-749-019-25 IC TOTX141 (DVD DIGITAL OUT) (GNZ7D)
IC771 6-703-547-01 IC TA7805LS
< JACK >
J201 1-774-785-11 JACK, PIN 1P (SUB WOOFER OUT)
(GNZ7D/GNZ8D)
J202 1-816-918-11 JACK, PIN 4P (TV/SAT)
< JUMPER RESISTOR >
JR211 1-216-837-11 METAL CHIP 22K 5% 1/10W
JR221 1-216-864-11 SHORT CHIP 0
JR251 1-216-837-11 METAL CHIP 22K 5% 1/10W
JR261 1-216-864-11 SHORT CHIP 0
JR304 1-216-864-11 SHORT CHIP 0
JR305 1-216-864-11 SHORT CHIP 0
JR382 1-216-864-11 SHORT CHIP 0 (GNZ7D)
JW291 1-216-864-11 SHORT CHIP 0
JW293 1-216-864-11 SHORT CHIP 0
JW415 1-216-864-11 SHORT CHIP 0 (GNZ7D)
JW416 1-216-864-11 SHORT CHIP 0 (GNZ7D)
JW417 1-216-864-11 SHORT CHIP 0 (GNZ7D)
< COIL >
L301 1-412-064-11 INDUCTOR 100uH (GNZ8D/GNZ9D)
L302 1-408-619-31 INDUCTOR 220uH (GNZ7D)
< TRANSISTOR >
Q212 8-729-905-35 TRANSISTOR 2SC4081-R
Q252 8-729-905-35 TRANSISTOR 2SC4081-R
