85
HCD-GNZ7D/GNZ8D/GNZ9D
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R653 1-216-851-11 METAL CHIP 330K 5% 1/10W
R654 1-216-835-11 METAL CHIP 15K 5% 1/10W
R655 1-216-812-11 METAL CHIP 180 5% 1/10W
R656 1-216-834-11 METAL CHIP 12K 5% 1/10W
R657 1-216-835-11 METAL CHIP 15K 5% 1/10W
R658 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R659 1-216-797-11 METAL CHIP 10 5% 1/10W
R701 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R702 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R703 1-216-821-11 METAL CHIP 1K 5% 1/10W
R704 1-216-821-11 METAL CHIP 1K 5% 1/10W
R705 1-216-821-11 METAL CHIP 1K 5% 1/10W
R706 1-216-821-11 METAL CHIP 1K 5% 1/10W
R711 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(GNZ8D/GNZ9D)
R712 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(GNZ8D/GNZ9D)
R713 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(GNZ8D/GNZ9D)
R714 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(GNZ9D)
R715 1-216-821-11 METAL CHIP 1K 5% 1/10W
(E2)
R715 1-216-864-11 SHORT CHIP 0 (EXCEPT E2)
R716 1-216-837-11 METAL CHIP 22K 5% 1/10W
(E2)
R717 1-216-821-11 METAL CHIP 1K 5% 1/10W
(E2)
R717 1-216-864-11 SHORT CHIP 0 (EXCEPT E2)
R718 1-216-837-11 METAL CHIP 22K 5% 1/10W
(E2)
R721 1-216-821-11 METAL CHIP 1K 5% 1/10W
R723 1-216-821-11 METAL CHIP 1K 5% 1/10W
R724 1-216-833-11 METAL CHIP 10K 5% 1/10W
R725 1-216-833-11 METAL CHIP 10K 5% 1/10W
R726 1-216-821-11 METAL CHIP 1K 5% 1/10W
R727 1-216-841-11 METAL CHIP 47K 5% 1/10W
R734 1-216-833-11 METAL CHIP 10K 5% 1/10W
R735 1-216-864-11 SHORT CHIP 0
R736 1-216-841-11 METAL CHIP 47K 5% 1/10W
R737 1-216-833-11 METAL CHIP 10K 5% 1/10W
R738 1-216-864-11 SHORT CHIP 0
R739 1-216-841-11 METAL CHIP 47K 5% 1/10W
R740 1-216-833-11 METAL CHIP 10K 5% 1/10W
R741 1-216-864-11 SHORT CHIP 0
R742 1-216-841-11 METAL CHIP 47K 5% 1/10W
R745 1-216-821-11 METAL CHIP 1K 5% 1/10W
(GNZ9D)
R751 1-216-809-11 METAL CHIP 100 5% 1/10W
R752 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R753 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R762 1-216-837-11 METAL CHIP 22K 5% 1/10W
R763 1-216-837-11 METAL CHIP 22K 5% 1/10W
R764 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R765 1-216-809-11 METAL CHIP 100 5% 1/10W
R767 1-216-809-11 METAL CHIP 100 5% 1/10W
R768 1-216-809-11 METAL CHIP 100 5% 1/10W
R769 1-216-809-11 METAL CHIP 100 5% 1/10W
R781 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(GNZ9D)
R782 1-216-841-11 METAL CHIP 47K 5% 1/10W
(GNZ9D)
R783 1-216-849-11 METAL CHIP 220K 5% 1/10W
(GNZ9D)
R784 1-216-837-11 METAL CHIP 22K 5% 1/10W
(GNZ9D)
R785 1-216-837-11 METAL CHIP 22K 5% 1/10W
(GNZ9D)
R790 1-216-809-11 METAL CHIP 100 5% 1/10W
R791 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R792 1-216-841-11 METAL CHIP 47K 5% 1/10W
R793 1-216-849-11 METAL CHIP 220K 5% 1/10W
R794 1-216-837-11 METAL CHIP 22K 5% 1/10W
R795 1-216-837-11 METAL CHIP 22K 5% 1/10W
R796 1-216-833-11 METAL CHIP 10K 5% 1/10W
R798 1-216-809-11 METAL CHIP 100 5% 1/10W
R799 1-216-833-11 METAL CHIP 10K 5% 1/10W
< TRANSFORMER >
T601 1-437-220-11 TRANSFORMER, BIAS OSCILLATION
*************************************************************
A-1095-784-A DMB10 BOARD, COMPLETE (GNZ9D:PH,SP)
A-1095-785-A DMB10 BOARD, COMPLETE
(GNZ9D:E3,E12,E13,E15)
A-1095-786-A DMB10 BOARD, COMPLETE (GNZ9D:E2,E51,MX)
A-1095-787-A DMB10 BOARD, COMPLETE (GNZ8D:PH,SP)
A-1095-788-A DMB10 BOARD, COMPLETE
(GNZ8D:E3,E12,E13,E15)
A-1095-789-A DMB10 BOARD, COMPLETE (GNZ7D:PH,SP)
A-1095-790-A DMB10 BOARD, COMPLETE
(GNZ7D:E3,E12,E13,E15)
A-1095-791-A DMB10 BOARD, COMPLETE (GNZ7D:E2)
A-1111-492-A DMB10 BOARD, COMPLETE (GNZ9D:TH)
A-1111-493-A DMB10 BOARD, COMPLETE (GNZ8D:TH)
A-1111-494-A DMB10 BOARD, COMPLETE (GNZ7D:TH)
A-1134-215-A DMB10 BOARD, COMPLETE (GNZ9D:AUS,EA)
A-1134-216-A DMB10 BOARD, COMPLETE (GNZ8D:EA)
A-1134-217-A DMB10 BOARD, COMPLETE (GNZ7D:EA)
***********************
< CAPACITOR >
C101 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C102 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C105 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C106 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C108 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C109 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C112 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C113 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C114 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C115 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C116 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C117 1-124-779-00 ELECT CHIP 10uF 20% 16V
C118 1-124-779-00 ELECT CHIP 10uF 20% 16V
C119 1-124-779-00 ELECT CHIP 10uF 20% 16V
C120 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C121 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
AUDIO DMB10
Ver. 1.1
New part of EEP ROM (IC103) on the DMB10 board or DMB11 board cannot be
used. Therefore, if the mounted DMB10 board (A-1095-784-A, etc.) is replaced,
exchange new EEP ROM (IC103) with that used before the replacement.
