97
HCD-GNZ7D/GNZ8D/GNZ9D
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< TRANSISTOR >
Q671 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA (GNZ9D)
Q672 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA (GNZ9D)
Q673 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA (GNZ9D)
Q682 8-729-029-66 TRANSISTOR DTC114ESA (GNZ9D)
Q683 8-729-119-78 TRANSISTOR 2SC2785-HFE (GNZ9D)
< RESISTOR >
R671 1-247-831-11 CARBON 1K 5% 1/4W
(GNZ9D)
R672 1-247-871-11 CARBON 47K 5% 1/4W
(GNZ9D)
R673 1-249-411-11 CARBON 330 5% 1/4W
(GNZ9D)
R674 1-247-871-11 CARBON 47K 5% 1/4W
(GNZ9D)
0 R675 1-208-602-11 METAL 0.22X2 2W F
(GNZ9D)
0 R676 1-208-602-11 METAL 0.22X2 2W F
(GNZ9D)
R677 1-247-831-11 CARBON 1K 5% 1/4W
(GNZ9D)
R678 1-249-431-11 CARBON 15K 5% 1/4W
(GNZ9D)
R679 1-247-879-11 CARBON 100K 5% 1/4W
(GNZ9D)
R680 1-260-076-11 CARBON 10 5% 1/2W F
(GNZ9D)
0 R681 1-212-881-11 FUSIBLE 100 5% 1/4W F
(GNZ9D)
R682 1-249-428-11 CARBON 8.2K 5% 1/4W
(GNZ9D)
R683 1-249-428-11 CARBON 8.2K 5% 1/4W
(GNZ9D)
0 R684 1-202-972-61 FUSIBLE 1 5% 1/4W F
(GNZ9D)
R685 1-249-439-11 CARBON 68K 5% 1/4W
(GNZ9D)
0 R686 1-216-457-00 METAL OXIDE 1.2K 5% 2W F
(GNZ9D)
R687 1-249-429-11 CARBON 10K 5% 1/4W
(GNZ9D)
R688 1-247-871-11 CARBON 47K 5% 1/4W
(GNZ9D)
R689 1-249-429-11 CARBON 10K 5% 1/4W
(GNZ9D)
R690 1-249-429-11 CARBON 10K 5% 1/4W
(GNZ9D)
R693 1-249-435-11 CARBON 33K 5% 1/4W
(GNZ9D)
< RELAY >
RY601 1-515-920-11 RELAY (24V) (GNZ9D)
*************************************************************
SUB TRANS BOARD
***************
1-533-217-41 HOLDER, FUSE (EXCEPT E12,E13,AUS,TH)
< CAPACITOR >
C902 1-164-159-11 CERAMIC 0.1uF 50V
C903 1-164-159-11 CERAMIC 0.1uF 50V
C905 1-162-306-11 CERAMIC 0.01uF 20% 16V
< CONNECTOR >
CN901 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
CN902 1-785-314-11 PIN, CONNECTOR (STRAIGHT) 2P
< DIODE >
D901 8-719-991-33 DIODE 1SS133T-77
< COIL >
L901 1-414-189-31 INDUCTOR 100uH
< TRANSISTOR >
Q901 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R901 1-249-429-11 CARBON 10K 5% 1/4W
R904 1-249-393-11 CARBON 10 5% 1/4W
< RELAY >
0RY901 1-755-324-11 RELAY
< SWITCH >
0S901 1-786-055-21 SELECTOR, VOLTAGE (VOLTAGE SELECTOR)
(GNZ7D:EXCEPT TH/GNZ8D:EXCEPT E12,E13,TH/
GNZ9D:EXCEPT E12,E13,AUS,MX,TH)
*************************************************************
A-1095-774-A SURROUND AMP BOARD, COMPLETE
(GNZ9D:EXCEPT TH)
A-1095-775-A SURROUND AMP BOARD, COMPLETE
(GNZ8D:EXCEPT TH)
A-1111-486-A SURROUND AMP BOARD, COMPLETE
(GNZ9D:TH)
A-1111-487-A SURROUND AMP BOARD, COMPLETE
(GNZ8D:TH)
********************
7-685-872-09 SCREW +BVTT 3X8 (S) (GNZ8D/GNZ9D)
< CAPACITOR >
C501 1-126-964-11 ELECT 10uF 20% 50V
(GNZ8D/GNZ9D)
C502 1-162-294-31 CERAMIC 0.001uF 10% 50V
(GNZ8D/GNZ9D)
C503 1-162-286-31 CERAMIC 220PF 10% 50V
(GNZ8D/GNZ9D)
C504 1-126-964-11 ELECT 10uF 20% 50V
(GNZ8D/GNZ9D)
C506 1-136-497-81 FILM 0.1uF 5% 50V
(GNZ8D/GNZ9D)
SUBWOOFER SUB TRANS SURROUND AMP
