11
HCD-M700
Jig For Checking DVD Board and DIGITAL Board Waveform
The special jig (J-2501-196-A) is useful for checking the waveform of the DVD board and DIGITAL board.
• Extention cable (10P)
(J-2501-219-A)
• Extention cable (27P)
(J-2501-220-A)
jig (10P
j
(J-2501-219-A)
jig (27P
j
(J-2501-220-A)
CN607
CN608
CN705
DVD board
CONTROL board
CN101
DIGITAL board
• DISC TRAY LOCK
If the disc tray does not open and the message “LOCKED” appears,
press the two buttons of ENTER/START and Z DVD at the same
for 5 seconds or longer.
Then the lock is released, the message “UNLOCKED” appears for
2 seconds and the disc tray opens.
